-12-
Mechanical Disassembly
Fig.4
v Optical Unit, Fans(FN903, FN904), Noise Filter removal
Noise filter
Optical unit
FN904
FN903
(T3x8)
(T3x6)x3
(T3x10)x4
(T3x6)
(T3x6)x2
(T3x8)x6
(T3x12)x2
