-71-
Electrical Adjustment
Service Adjustment Data Table
These initial values are the reference data written from the
CPU ROM to memory IC when replaced new memory IC. The
adjustment items indicated with “✻” are required to readjust fol-
lowing to the “Electrical adjustments”. Other items should be
used with the initial data value.
GROUP NO. ITEM FUNCTION RANGE INITIAL VALUE NOTE
0 Temperature Monitor Indication
0 MCP9801 Duct (Temp) Monitor (°C) Temp. Sensor (Intake) x 10 – –
1 MCP9801 Inner (Temp) Monitor (°C) Temp. Sensor (Inner) x 10 – –
2 Thermistor Monitor (°C) Temp. Thermistor (Inner) x 10 – –
3 Thermistor Monitor DAC value – –
1 Pressure Monitor Indication
0 Pressure Monitor Pressure (Compensation No) DAC – –
1 Pressure Monitor Pressure (Compensation Yes) DAC – –
2 Pressure Monitor Pressure (Compensation Yes) [mmHg]
3 Pressure Monitor Pressure (Compensation Yes) [hpa] – –
4 Flow Sensor Monitor (Read only)
0 Flow Sensor Monitor Flow Sensor – –
10 RS232C Set
0 Baud rate RS232C Baud rate (0 : 19200 / 1 : 9600) 0 / 1 0
11 PJ-Net Set
0 Reset Disable PJ-Net Reset (0 : Enable / 1 : Disable) 0 / 1 0
20 Logo On/Off
0 Logo On/Off (0 : Menu Operation / 1 : Prohibition) 0 / 1 0
30 Color Shading / Gamma Correction
0 Color shading Correction On /Off (0 : Off / 1 : On) Not memorized 0 / 1 1
1 Gamma Correction On/Off (0 : Off / 1 : On) Not Memorized 0 / 1 1
40 Dimmer Control
0 Dimmer On/Off (0 : Menu Operation / 1 : Off) 0 / 1 1 (Shipment:0)
1 Dimmer Level LAMP1 (0 : 264W ~ 15 : 330W) 0 ~ 15 15
2 Dimmer Level LAMP2 (0 : 264W ~ 15 : 330W) 0 ~ 15 15
50 Auto Picture Control
0 Auto Picture On/Off (0 : Menu Operation / 1 : Off) 0 / 1 1 (Shipment:0)
91 Projector Error Logs History
0 Warning_Log_1 Latest Error Log 0 ~ 32767 0
~ : : :
49 Warning_Log_50 50th older Error Log 0 ~ 32767 0
50 Warning_Log_Reset Resets the logs when the value is set to 10. 0 ~ 10 0
100 Shutter Operation
0 PRE_MOTION Pre-Motion Enable (0: Enable, 1: Disable) 0 ~ 1 1 (Shipment:0)
1 CMP_TRM Chattering Detection Time 0 ~ 65535 7000
2 OUT_DLY_TRM Output Time 0 ~ 65535 15000
3 CMP_CHK_CNT Detection Count 0 ~ 15 5
4 OPEN_DLY Open Delay Time 0 ~ 63 0
5 CLOSE_DLY Close Delay Time 0 ~ 63 0
113 Lamp Reset Counter
0 Lamp 1 Lamp 1 Total Reset Count 0 ~ 127 0
1 Lamp 2 Lamp 2 Total Reset Count 0 ~ 127 0
115 Lamp Go Out
0 Lamp Go Out 0 : Disable / 1 : Enable 0 / 1 0
116 Lamp Replace Display
0 Lamp Replace Display 0 : Disable / 1 : Enable 0 / 1 1
117 Lamp Life Test
0 Lamp Life Test Enable 0: Disable / 1: Enable For safety test 0
1 Lamp Om time 1
2 Lamp Off time 3
3 Lamp Total time 0
118 Half Lamp Auto Change
0 Half Lamp Auto Change ON/OFF 0: Off, 1: On 0 / 1 0
1 Half Lamp Timer Start unit: hour 0 ~ 24 0
2 Half Lamp Timer Interval unit: hour 1 ~ 255 24
3 Half Lamp Timer Count unit: hour - -
4 Half Lamp Auto CHange Store 0: Clear after AC Off, 1: Not Clear after AC Off 0 / 1 0
To Next Page
