-51-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
1 Sclaler Vertical Vertical Scaler Edit 100 68-132
2 Connect Seperate/Connect Edit 0 0-1 0:Seperate, 1: Connect
3 Position Horizontal Horizontal Postion Correction 100 85-115
4 Position Vertical Vertical Position Correct 100 85-115
Group
280
AutoPC Adjust
0 AutoPCAdjustEnable
Auto-PC Adj Operation Enable if
Un-supported Signal Input
0 0-1 0:Enabel, 1:Disable
1 Frequency Step Frequency Steps of Total Dot 1 0-3
2 Frequency Threshold Total Dot Freqency Threshold 5 0-10 0[]<-- - --> 10[Not matched]
3 Fine Phase Do Phase Adj after Total Dot Adj. 1 0-1 0;Excutes Fine Phase; 1:Not Excute
4 BLKDET Black Level Detection Area 1 0 - 7
5 PHASEMSK Phase Detection Filter 0 0 - 3
0: Effective All Bit,
1: Disable Lower 1 bit
2: Disable Lower 2 bit, 3: Disable
Lower 3 bit
Group
290
PanelType * Panel Type Check
0 GammaL/R-View Current Setting Check 0 0-20
0: Gamma for L-Turn
20: Gamma for R-Turn * Read only
1 GammaL/R-Change Setting of Gamma 10 0-20
Sets L-Turn Gamma if the Value is
set to 0.
Sets R-Turn Gamma if the Value is
set to 20.
Group
500
Composite (NTSC) Composite / S-Video
0
1 Disp Dots 668 0 ~ 4095
2 H Back Porch 28 0 ~ 4095
3 V Back Porch 18 0 ~ 4095
4 Disp Line 458 0 ~ 4095
Group
501
Composite (PAL) Composite / S-Video
0
1 Disp Dots 658 0 ~ 4095
2 H Back Porch 34 0 ~ 4095
3 V Back Porch 22 0 ~ 4095
4 Disp Line 536 0 ~ 4095
Group
502
Composite (SECAM) Composite / S-Video
0
1 Disp Dots 652 0 ~ 4095
2 H Back Porch 28 0 ~ 4095
3 V Back Porch 22 0 ~ 4095
4 Disp Line 536 0 ~ 4095
Group
510
SCART(480i)
0
1 Disp Dots 674 0 ~ 4095
2 H Back Porch 132 0 ~ 4095
3 V Back Porch 43 0 ~ 4095
4 Disp Line 452 0 ~ 4095
Group
511
SCART (575i)
0
1 Disp Dots 650 0 ~ 4095
2 H Back Porch 152 0 ~ 4095
3 V Back Porch 68 0 ~ 4095
4 Disp Line 514 0 ~ 4095
Group
520
YCbCr (480i)
0 Total Dots 858 0 ~ 4095
1 Disp Dots 670 0 ~ 4095
2 H Back Porch 146 0 ~ 4095
3 V Back Porch 48 0 ~ 4095
4 Disp Line 458 0 ~ 4095
