-61-
Chassis Block Diagrams
SCL0
SDA0
IC301
SCALER
<PW190>
293
212
VGA_SCL
VGA_SDA
101
21
IC8821
TEMP
SENSOR 2
<ADT75BRMZ>
MAIN
6
SCL1
SDA1
211
294
5
IC1371
CONTROL
MEMORY
21
IC8831
TEMP
SENSOR 3
<ADT75BRMZ>
6
7
5
IC1051
VGA HDCP
MEMORY
DDC_SW
Q1012
DSub15
21
IC8811
TEMP
SENSOR 1
<MCP9801T-M>
6
SCL2
SDA2
290
208
5
IC5002
AIC3105
IIC bus control circuit
