-73-
Parts Location Diagrams
KR8-XK220000, KS8-XK260000
Cabinet bottom-2 assembly
C02
M06
FN004
C11
C01
M10
M09
M07
M05
M11
FN001
FN003
FN005
L04 (Projection)
S04
Projection Lens
