Group: 0 TC90A26
0Y-EQ_GAIN 3 0 ~ 3
1Y-EQ_N_C_LIM 3 0 ~ 3
2V-ENH_GAIN 4 0 ~ 7
3 V_ENH_CORING 2 0 ~ 3
4 NTSC443_SW 1 0 ~ 1 Input signal setting 0:NTSC4.43 1:PAL60 (Only effective for NTSC4.43 signal inputs)
Group: 1 uPD64082
0 NRMD 0 0 ~ 3
1 HDP 4 0 ~ 7
2 CDL 4 0 ~ 7
3DYCOR 4 0 ~ 15
4DYGAIN 15 0 ~ 15
5 DCCOR 2 0 ~ 15
6 DCGAIN 13 0 ~ 15
7 YNRK 0 0 or 1
8 YNRINV 0 0 or 1
9 YNRLIM 0 0 ~ 3
10 CNRK 0 0 or 1
11 CNRINV 0 0 or 1
12 CNRLIM 0 0 ~ 3
13 VAPGAIN 2 0 ~ 15
14 VAPINV 2 0 ~ 15
15 YPFT 3 0 ~ 3
16 YPFG 9 0 ~ 15
17 V1PSEL 3 0 ~ 3
18 VEGSEL 3 0 ~ 3
19 CC3N 0 0 or 1
20 SELD2FH 1 0 or 1
21 SELDFL 1 0 or 1
22 YHCOR 1 0 ~ 3
23 HPLLFS 1 0 or 1
24 PLLFG 1 0 or 1
25 KILR 3 0 ~ 15
26 HSSL 12 0 ~ 15
27 VSSL 3 0 ~ 15
28 BGPS 7 0 ~ 15
29 BGPW 3 0 ~ 15
Group: 2 TB1274
0 TINT 32 0 ~ 63
1 SHP_EQ 2 0 ~ 3
2 SHP_FO 2 0 ~ 3
3 SHP_GAIN 8/8/8/8/8/8/8 0 ~ 15 VideoNT/ PAL,PALM,PALN/SECAM,BW60,BW50/ NT443/ PAL60/ S-Video/YCbCr
4 Y_OUT_LEVEL 31/32/32/32/32 0 ~ 63 VideoNT/ NT443/ PAL,PALM,PALN/ PAL60/ SECAM,BW
0.7V 32/32/32/32/32/32 S-VideoNT,BW/ NT443/ PAL,PALM,PALN/ PAL60/ SECAM/ YCbCr
5 C_OUT_LEVEL 12/12/15/15/22 0 ~ 63 VideoNT/ NT443/ PAL,PALM,PALN/ PAL60/ SECAM,BW
0.6V 12/12/15/15/22/18/20 S-VideoNT,BW/ NT443/ PAL,PALM,PALN/ PAL60/ SECAM/480i/575i
6 Y_DELAY 5/5/4/4/4 0 ~ 15 Video NT,BW60/ PAL,PALM,PALN,BW50/ SECAM/NT443/PAL60
4/4/3/3/4 S-Video NT,BW60/PAL,PALM,PALN,BW50/ SECAM/ NT443/ PAL60
7 COL_SYS - -
8X’TAL - -
9 NOISE_DET - - Read Only
10 V_FREQ - -
11 Vert. Std - -
12 CID - -
13 VSIG - -
14 MVM 0 0 or 1
15 AFC_GAIN 1 0 ~ 3
16 SECAM_GP 7 0 ~ 7
Group: 3 CXA2101
0 PICTURE 15/25/25 0 ~ 63 NT,PAL,SECAM,NT443,PALM,PALN,480i,575i/ 480p,575p/ 1080i,1035i,720p ✻ A/D input Adj.[G]
1 BRIGHT 50/50/50 0 ~ 63 NT,PAL,SECAM,NT443,PALM,PALN,480i,575i/ 480p,575p/ 1080i,1035i,720p ✻ Pedestal Adj.[G]
2 R_DRIVE 31/31/31 0 ~ 63 NT,NT443,PAL,PALM,PALN,480i,575i/ 480p,575p/ 1080i,1035i,720p ✻ A/D input Adj.[R]
3 G_DRIVE 31 0 ~ 63
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments
● Service Adjustment Data Table
These initial values are the reference data written from the CPU
ROM to memory IC when replaced new memory IC. The adjust-
ment items indicated with “✻” are required to readjust following
to the “Electrical adjustments”. Other items should be used with
the initial data value.
