-12-
42 Real/Cinema GAMMA 14 512/512 385 ~ 639
43 Real/Cinema GAMMA 15 512/512 385 ~ 639
44 r_mid2_level 464 0 ~ 1023 _C9D
45 r_mid1_level 560 0 ~ 1023 _C9E
46 r_max_level 632 0 ~ 1023 _C9F
47 g_mid2_level 464 0 ~ 1023 _CA1
48 g_mid1_level 560 0 ~ 1023 _CA2
49 g_max_level 632 0 ~ 1023 _CA3
50 b_mid2_level 464 0 ~ 1023 _CA5
51 b_mid1_level 560 0 ~ 1023 _CA6
52 b_max_level 632 0 ~ 1023 _CA7
53 V-line Correction_R2 0 0 ~ 255 _C48
54 V-line Correction_G2 0 0 ~ 255 _C4D
55 V-line Correction_B2 0 0 ~ 255 _C52
Group: 5 DAC
0 B_VIDEO_CENTER 120 0 ~ 255 dac1 ✻ Video Center Adj.[B]
1 G_VIDEO_CENTER 120 0 ~ 255 dac1 ✻ Video Center Adj.[G]
2R_VIDEO_CENTER 120 0 ~ 255 dac1 ✻ Video Center Adj.[R]
3 REF_B 100 0 ~ 255 dac1 ✻ Black Level Adj.[B]
4 REF_G 100 0 ~ 255 dac1 ✻ Black Level Adj.[G]
5 REF_R 100 0 ~ 255 dac1 ✻ Black Level Adj.[R]
6 SIG1 135 0 ~ 255 NRS B ✻ NRS Adj.-1
7 NRSA 143 0 ~ 255 NRS A
8-- 112 ✻ NRS Adj.-2
9-- 170
10 R_V_COM 153 0 ~ 255 dac2 ✻ Common Center Adj.[R]
11 G_V_COM 153 0 ~ 255 dac2 ✻ Common Center Adj.[G]
12 B_V_COM 153 0 ~ 255 dac2 ✻ Common Center Adj.[
B]
13 R_BLK_DC 115/110/115 0 ~ 255 dac3 video/1080i,1035i,720p/480p,525p ✻ Pedestal Adj.[
R]
14 B_BLK_DC 115/110/115 0 ~ 255 dac3 video/1080i,1035i,720p/480p,525p ✻ Pedestal Adj.[B]
15 B_CLMP 30 0 ~ 255 dac4 ✻ PC Pedestal Adj.[B]
16 G_CLMP 30 0 ~ 255 dac4 ✻ PC
Pedestal Adj.[G]
17 R_CLMP 30 0 ~ 255 dac4 ✻ PC
Pedestal Adj.[R]
Group: 6 AD9883
0pll_divide 938/904 0 ~ 4095 adr01,02(7-4) 625line/525line
1 vco_range 0 0 ~ 3 adr03(7-6)
2 charge_pump_current 1/1 0 ~ 7 adr03(5-3) 625line/525line
3 ad_clk_phase 8/8 0 ~ 31 adr04(7-3) 625line/525line
4clp_placement 128 0 ~ 255 adr05
5 clp_width 50 0 ~ 255 adr06
6 hsync_out_pulse_width 64 0 ~ 255 adr07
7r_gain 255 0 ~ 255 adr08
8 g_gain 255 0 ~ 255 adr09
9 b_gain 255 0 ~ 255 adr0A
10 r_offset 60 0 ~ 128 adr0B(7-1) ✻ Offset Adj.[R]
11 g_offset 60 0 ~ 128 adr0C(7-1) ✻ Offset
Adj.[G]
12 b_offset 60 0 ~ 128 adr0D(7-1) ✻ Offset Adj.[B]
13 sync_reg 208 0 ~ 255 adr0E
14 clp_corst_pow 154 0 ~ 255 adr0F
15 clp_sel 5 0 ~ 7 adr10(2-0)
16 read_status - 0 ~ 255 read_only adr14
17 ic_ver - 0 ~ 255 read_only adr00
Group: 7 LP05
0 LP05_R_GAIN_ud 128 0 ~ 255
1 LP05_G_GAIN_ud 128 0 ~ 255
2 LP05_B_GAIN_ud 128 0 ~ 255
3 LP05_TURBO_GAIN_ud 18 0 ~ 255
4 LP05_SHP_EN_SET_ud 805 0 ~ 4095 Set appurture compensation effective period.
5 LP05_SHP_EN_RST_ud 14 0 ~ 4095 Set appurture compensation effective period.
6 LP05_AB_ON_ud 0 0 ~ 3 Select appurture compensation effective period. 3: 3 point front/back 1: 2 point front/back0: 1 point front/back 2:
Not selection
7 LP05_EGE_ud 0 0 ~ 3 Select Frequency characteristics data
Group: 10 Option
0 Lamp Time Monitor - - Read only
1 RS232C Baudrate 0 0 ~ 1 0: 19200bps 1: 9600bps
2 Shootout Mode 0 0 ~ 1 1: Shoot Out Mode Enable 0: Disable
3 Cooling Time 3 0 ~ 15 Set cooling period, 1: 30 sec. 3: 90 sec. 15: 450 sec. 0: continus
4Hi-Land SW 0 0 ~ 255 0: Normal 1: Highland mode (Fan spin speed max.)
5V-Douki SW 0 0 ~ 1 0: Syncronized Vertical 1: non-syncronized Vertical
Electrical Adjustments
No. Adjustment Item Initial Value Range Input source / Description
