Sanyo PLC-XP46 User Manual

-13-
6 Lamp-use time accumulated - - Read only
7Net Board Reset 1 0 ~ 1 0: Invalid , 1: Valid
8Key Stone Option 0 0 ~ 1 0: Fixed, 1: Change with inpt signal
9 Logo Off 0 0 ~ 1 0: follow ro menu setting, 1: No logo display
10 Airmouse prohibition 0 0 ~ 1 0: follow to menu setting, 1: prohibition of airmaouse function
10 Auto PC Adj. Disable 0 0 ~ 1 0: fAuto PC Adjust Enable 1:Auto PC Adjust Disable
Group: 11 Fan Control
0FAN_TEMP_A_WARNING 46 30 ~ 100 Temerature to judge abnormal A (Not memorized) Inside projector
1FAN_TEMP_B_WARNING 62 30 ~ 100 Temerature to judge abnormal B (Not memorized) Optical
2FAN_TEMP_C_WARNING 18 0 ~ 100 Temerature to judge abnormal A (Not memorized)Detect the filter clogged
3FAN_CONTROL_SW 0 0 or 1 0: Auto-FanControl 1: Manual
4FAN_A_SPEED 174/251 0 ~ 255 This is effective when FAN_CONTROL_SW is set to “1”.
5FAN_B_SPEED 210/242 0 ~ 255 Normal/Eco mode
6FAN_TEMP_A_MONI - - Read only
7FAN_TEMP_B_MONI - -
8FAN_TEMP_C_MONI
9FAN_PRESSURE - - Read only
Group: 12 PC Real / AV Cinema
0 PC Real Contrast 32 0 ~ 63
1 PC Real Brightness 32 0 ~ 63
2 PC Real Red 32 0 ~ 63
3 PC Real Green 32 0 ~ 63
4PC Real Blue 32 0 ~ 63
5 PC Real Gamma 8 0 ~ 15
6AV Cinema Contrast 32 0 ~ 63
7AV Cinema Brightness 32 0 ~ 63
8AV Cinema Color 32 0 ~ 63
9AV Cinema Tint 32 0 ~ 63
10 AV Cinema Red 32 0 ~ 63
11 AV Cinema Green 32 0 ~ 63
12 AV Cinema Blue 32 0 ~ 63
13 AV Cinema Sharpness 15 0 ~ 31
14 AV Cinema Gamma 8 0 ~ 15
15 AV Cinema N.R. 0 0 or 1
16 AV Cinema PROGRESSIVE 1 0 or 1
Group: 100 ICS_LP_data
0 LP05_R5_VBLKPOL 0 0 ~ 1 R5=ADR133
1 LP05_R5_VBLKS 0 0 ~ 2047 Change value automatically according to selected signal.
2 LP05_R5_VBLKR 9/14/28/ 0 ~ 2047 NTSC & 480i / PAL & SECAM & 525i / 1035i & 1080i60
28/23/30/35 1080i50 / 720P / 480P / 575P
3 LP05_R6_HBLKPOL 0 0 ~ 1 R6=ADR134
4 LP05_R6_HBLKS 16 0 ~ 4095 Change value automatically according to selected signal.
5 LP05_R6_HBLKR 32 0 ~ 4095 NTSC & 480i / PAL & SECAM & 525i / 1035i & 1080i60 / 1080i50 / 720P / 480P / 575P
6 LP05_R7_CLPPOL 0 0 ~ 1 R7=ADR135
7 LP05_R7_CLPS 175/175/75/ 0 ~ 4095 Change value automatically according to selected signal.
75/75/156/162 NTSC & 480i / PAL & SECAM & 525i / 1035i & 1080i60 /
8LP05_R7_CLPR 270/270/160/ 0 ~ 4095 1080i50 / 720P / 480P / 575P
155/185/260/290
9 LP05_R8_VOFFON 0/1 0 ~ 1 R8=ADR136
10 LP05_R8_VOFFS 0 0 ~ 2047 Change value automatically according to selected signal.
11 LP05_R8_VOFFR 0/0/20/20/10/7/7 0 ~ 2047 NTSC & 480i / PAL & SECAM & 525i / 1035i & 1080i60 / 1080i50 / 720P / 480P / 575P
12 LP05_R9_VBLK2POL 0 0 ~ 1 R9=ADR137
13 LP05_R9_VBLK2POS 16 0 ~ 2047 Change value automatically according to selected signal.
14 LP05_R9_VBLK2WID 32 0 ~ 2047 NTSC & 480i / PAL & SECAM & 525i / 1035i & 1080i60 / 1080i50 / 720P / 480P / 575P
15 LP05_RA_HBLK2POL 0 0 ~ 1 RA=ADR138
16 LP05_RA_HBLK2POS 0 0 ~ 4095 Change value automatically according to selected signal.
17 LP05_RA_HBLK2WID 300/300/127/ 0 ~ 4095 NTSC & 480i / PAL & SECAM & 525i / 1035i & 1080i60
120/185/230/265 1080i50 / 720P / 480P / 575P
18 ICS_R0_EnDLS 0 0 ~ 1 R0
19 ICS_R0_EnPLS 1 0 ~ 1 NTSC & 480i / PAL & SECAM & 525i / 1035i & 1080i60 / 1080i50 / 720P / 480P / 575P
20 ICS_R0_Func_Sel 0 0 ~ 1
21 ICS_R0_Fbk_Sel 0 0 ~ 1
22 ICS_R0_Fbk_Pol 0 0 ~ 1
23 ICS_R0_Ref_Pol 1 0 ~ 1
24 ICS_R0_PD_Pol 0 0 ~ 1
25 ICS_R0_Pden 1 0 ~ 1
26 ICS_R1_PSD 2 0 ~ 3 R1
27 ICS_R1_PFD 6 0 ~ 7 NTSC & 480i / PAL & SECAM & 525i / 1035i & 1080i60 / 1080i50 / 720P / 480P / 575P
28 ICS_R3_FBD 2432 0 ~ 8191 R3_R2
Electrical Adjustments
No. Adjustment Item Initial Value Range Input source / Description
