Sanyo PLC-XP46 User Manual

-14-
NTSC & 480i / PAL & SECAM & 525i / 1035i & 1080i60 / 1080i50 / 720P / 480P / 575P
29 ICS_R4_Fil_Sel 0 0 ~ 1 R4
30 ICS_R4_DPA_OS 0 0 ~ 63 NTSC & 480i / PAL & SECAM & 525i / 1035i & 1080i60 / 1080i50 / 720P / 480P / 575P
31 ICS_R5_Mask_Rev 0 0 ~ 63 R5
32 ICS_R5_DPA_Res 0 0 ~ 3 NTSC & 480i / PAL & SECAM & 525i / 1035i & 1080i60 / 1080i50 / 720P / 480P / 575P
33 ICS_R6_Out_Scl 0 0 ~ 3 R6
34 ICS_R6_Ck2_Inv 0 0 ~ 1 NTSC & 480i / PAL & SECAM & 525i / 1035i & 1080i60 / 1080i50 / 720P / 480P / 575P
35 ICS_R6_OE_F 1 0 ~ 1
36 ICS_R6_OE_T2 0 0 ~ 1
37 ICS_R6_OE_P2 0 0 ~ 1
38 ICS_R6_OE_Tck 1 0 ~ 1
39 ICS_R6_OE_Pck 0 0 ~ 1
40 ICS_R7_In_Sel 0 0 ~ 1 R7
41 ICS_R7_Osc_Div 0 0 ~ 127 NTSC & 480i / PAL & SECAM & 525i / 1035i & 1080i60 / 1080i50 / 720P / 480P / 575P
42 ICS_R8_PLL 5 0 ~ 15 R8
43 ICS_R8_DPA 10 0 ~ 15 NTSC & 480i / PAL & SECAM & 525i / 1035i & 1080i60 / 1080i50 / 720P / 480P / 575P
Group: 500 ADC
0 ADC R-OFFSET 128 0 ~ 255
1 ADC G-OFFSET 128 0 ~ 255
2 ADC B-OFFSET 128 0 ~ 255
3 ADC R-GAIN 255 0 ~ 255
4 ADC G-GAIN 255 0 ~ 255
5 ADC B-GAIN 255 0 ~ 255
Group: 502 Keystone Aspect
0 ASPECT_SCALE 64 0 ~ 255
1 ASPECT_POSITION 64 0 ~ 255
2 OSD V Position 0 0 ~ 255
3 OSD H Position 0 0 ~ 255
4V Scaler 50 0 ~ 255
5V Scaler Position 2500 0 ~ 5000
6H Scaler 50 0 ~ 255
7H Scaler Position 2500 0 ~ 5000
Group: 510 NTSC Gakaku
0 NTSC TOTAL DOTS 905 0 ~ 2048 Not used
1 NTSC DISP DOTS 1410 0 ~ 2048 NT
2 NTSC H BACK PORCTH 294 0 ~ 2048
3 NTSC V BACK PORCTH 40 0 ~ 2048
4 NTSC DISP LINE 456 0 ~ 2048
5 NTSC CLAMP 0 0 ~ 2048
Group: 511 PAL Gakaku
0PAL TOTAL DOTS 939 0 ~ 2048 Not used
1PAL DISP DOTS 1426 0 ~ 2048 PAL
2PAL H BACK PORCTH 298 0 ~ 2048
3PAL V BACK PORCTH 51 0 ~ 2048
4PAL DISP LINE 534 0 ~ 2048
5PAL CLAMP 0 0 ~ 2048
Group: 512 HDTV 1080i-60 Gakaku
0 TOTAL DOTS 1203 0 ~ 2048
1 DISP DOTS 1024 0 ~ 2048 1080i60
2H BACK PORCTH 143 0 ~ 2048
3V BACK PORCTH 53 0 ~ 2048
4 DISP LINE 1052 0 ~ 2048
5 CLAMP 7 0 ~ 2048
Group: 513 HDTV 1080i-50 Gakaku
0 TOTAL DOTS 1444 0 ~ 2048
1 DISP DOTS 1024 0 ~ 2048 1080i50
2H BACK PORCTH 143 0 ~ 2048
3V BACK PORCTH 53 0 ~ 2048
4 DISP LINE 1052 0 ~ 2048
5 CLAMP 7 0 ~ 2048
Group: 514 HDTV 1035i Gakaku
0 TOTAL DOTS 1203 0 ~ 2048
1 DISP DOTS 1024 0 ~ 2048 1035i (tempolary)
2H BACK PORCTH 143 0 ~ 2048
3V BACK PORCTH 90 0 ~ 2048
4 DISP LINE 1010 0 ~ 2048
5 CLAMP 7 0 ~ 2048
Group: 515 HDTV 720p Gakaku
No. Adjustment Item Initial Value Range Input source / Description
