-15-
0TOTAL DOTS 1650 0 ~ 2048
1 DISP DOTS 1248 0 ~ 2048 720p
2H BACK PORCTH 317 0 ~ 2048
3V BACK PORCTH 34 0 ~ 2048
4 DISP LINE 700 0 ~ 2048
5 CLAMP 8 0 ~ 2048
Group: 516 HDTV 575p Gakaku
0TOTAL DOTS 1408 0 ~ 2048
1 DISP DOTS 1076 0 ~ 2048 575p
2H BACK PORCTH 267 0 ~ 2048
3V BACK PORCTH 67 0 ~ 2048
4 DISP LINE 530 0 ~ 2048
5 CLAMP 8 0 ~ 2048
Group: 517 HDTV 480p Gakaku
0TOTAL DOTS 1285 0 ~ 2048
1 DISP DOTS 1024 0 ~ 2048 480p (top bottom left right 7)
2H BACK PORCTH 212 0 ~ 2048
3V BACK PORCTH 47 0 ~ 2048
4 DISP LINE 460 0 ~ 2048
5 CLAMP 7 0 ~ 2048
Group: 518 RGB NTSC Gakaku
0TOTAL DOTS 1330 0 ~ 2048
1 DISP DOTS 1038 0 ~ 2048 RGB NTSC
2H BACK PORCTH 226 0 ~ 2048
3V BACK PORCTH 44 0 ~ 2048
4 DISP LINE 457 0 ~ 2048
5 CLAMP 1 0 ~ 2048
Group: 519 RGB PAL Gakaku
0TOTAL DOTS 1366 0 ~ 2048
1 DISP DOTS 1040 0 ~ 2048 RGB PAL
2H BACK PORCTH 257 0 ~ 2048
3V BACK PORCTH 60 0 ~ 2048
4 DISP LINE 536 0 ~ 2048
5 CLAMP 4 0 ~ 2048
Group: 900 LC24049 Timing Controller
0 HCK PHASE 10 0 ~15
1 RCK PHASE ADJ 16 0 ~ 255
2 GCK PHASE ADJ 16 0 ~ 255
3 BCK PHASE ADJ 16 0 ~ 255
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments
