Sanyo PLC-XP46 - Electrical Parts List; Connect Board; Sensor 1 Board; Integrated Circuits

MA8-XP4602/MA8-XP46L01
-19-
Electrical Parts List
610 293 1846 ASSY,PWB,CONNECT MA8A
610 294 8233 ASSY,PWB,SENSOR 1 MA8A
INTEGRATED CIRCUIT
IC1691 409 481 8602 IC LM76CHMX-5
CAPACITOR
C1691 403 281 5205 CERAMIC 0.22U Z 16V
C1692 403 155 1609 CERAMIC 33P J 50V
C1693 403 155 1609 CERAMIC 33P J 50V
RESISTOR
R1691 401 105 0405 MT-GLAZE 100 JA 1/16W
R1692 401 105 0306 MT-GLAZE 10 JA 1/16W
R1693 401 105 0306 MT-GLAZE 10 JA 1/16W
610 296 9351 ASSY,PWB,A/V MA8AA
TRANSISTOR
Q2001 405 134 5905 TR 2SA1037AK-T146-R
Q2002 405 134 5905 TR 2SA1037AK-T146-R
Q2003 405 134 5905 TR 2SA1037AK-T146-R
Q2004 405 014 4509 TR 2SC2412K T146 R
Q2006 405 014 4509 TR 2SC2412K T146 R
Q5007 405 014 4509 TR 2SC2412K T146 R
Q5008 405 014 4509 TR 2SC2412K T146 R
Q5201 405 014 4509 TR 2SC2412K T146 R
Q5202 405 014 4509 TR 2SC2412K T146 R
Q5203 405 014 4509 TR 2SC2412K T146 R
Q5204 405 014 4509 TR 2SC2412K T146 R
Q7262 405 014 4509 TR 2SC2412K T146 R
INTEGRATED CIRCUIT
IC101 409 470 2604 IC AD8183ARU-REEL7
IC1031 409 461 7304 IC AD8057ART-REEL7
IC1041 409 461 7304 IC AD8057ART-REEL7
IC1051 409 461 7304 IC AD8057ART-REEL7
IC3801 409 380 6303 IC HIN232CB
409 273 3501 IC SP232ACT
IC3802 409 395 5902 IC TC7SH00FU-(TE85L)
IC3803 410 296 5700 IC TWM7000-151020
IC3804 410 275 5806 IC TWM7000-162020
410 275 5707 IC TWM7000-162020
IC5001 409 051 2702 IC TC4052BF(EL)
IC5201 409 462 0304 IC 24LC21AT/SN
IC5202 409 051 2900 IC TC4053BF(EL)
IC5203 409 462 6009 IC AD8185ARU-REEL7
IC5204 409 407 7900 IC EL4332CS
IC7141 409 484 2003 IC BA7078AF-E2
IC7221 410 343 7008 IC SN74AHCT1G14DBVR
IC7222 410 343 7008 IC SN74AHCT1G14DBVR
CAPACITOR
C1004 403 164 0204 CERAMIC 0.1U Z 25V
C1006 403 164 0204 CERAMIC 0.1U Z 25V
C1007 403 304 2105 ELECT 47U M 6.3V
C1008 403 164 0204 CERAMIC 0.1U Z 25V
C1009 403 155 1609 CERAMIC 33P J 50V
C101 403 321 2607 ELECT 10U M 16V
C1011 403 164 0204 CERAMIC 0.1U Z 25V
C1012 403 155 1609 CERAMIC 33P J 50V
C1013 403 164 0204 CERAMIC 0.1U Z 25V
C1014 403 155 1609 CERAMIC 33P J 50V
C1016 403 164 0204 CERAMIC 0.1U Z 25V
C1017 403 304 2105 ELECT 47U M 6.3V
C1018 403 164 0204 CERAMIC 0.1U Z 25V
C102 403 321 2607 ELECT 10U M 16V
C1021 403 157 4202 CERAMIC 220P J 50V
C1022 403 283 6309 CERAMIC 1U Z 10V
C1023 403 304 2105 ELECT 47U M 6.3V
C1024 403 113 3805 CERAMIC 1000P K 50V
C1026 403 113 3805 CERAMIC 1000P K 50V
C1027 403 113 3805 CERAMIC 1000P K 50V
C1028 403 113 3805 CERAMIC 1000P K 50V
C103 403 321 2607 ELECT 10U M 16V
C104 403 164 0204 CERAMIC 0.1U Z 25V
C106 403 164 0204 CERAMIC 0.1U Z 25V
C107 403 164 0204 CERAMIC 0.1U Z 25V
C108 403 164 0204 CERAMIC 0.1U Z 25V
C109 403 149 9208 CERAMIC 0.01U Z 50V
C111 403 164 0204 CERAMIC 0.1U Z 25V
C112 403 280 1604 ELECT 220U M 16V
C113 403 164 0204 CERAMIC 0.1U Z 25V
C114 403 280 1604 ELECT 220U M 16V
C2007 403 149 9208 CERAMIC 0.01U Z 50V
C2008 403 304 3300 ELECT 47U M 16V
C2011 403 321 2607 ELECT 10U M 16V
C2012 403 321 2607 ELECT 10U M 16V
C2013 403 321 2607 ELECT 10U M 16V
C2014 403 164 0204 CERAMIC 0.1U Z 25V
C2016 403 321 2607 ELECT 10U M 16V
C2061 403 164 0204 CERAMIC 0.1U Z 25V
C2081 403 304 1801 ELECT 100U M 6.3V
C2082 403 304 1801 ELECT 100U M 6.3V
C2083 403 304 1801 ELECT 100U M 6.3V
C2086 403 283 6309 CERAMIC 1U Z 10V
C2087 403 283 6309 CERAMIC 1U Z 10V
C2088 403 229 3508 ELECT 100U M 16V
C2091 403 304 1801 ELECT 100U M 6.3V
C2092 403 304 1801 ELECT 100U M 6.3V
C3801 403 283 6309 CERAMIC 1U Z 10V
C3802 403 162 6208 ELECT 1U M 50V
C3803 403 162 6208 ELECT 1U M 50V
C3804 403 162 6208 ELECT 1U M 50V
C3807 403 283 6309 CERAMIC 1U Z 10V
C3808 403 283 6309 CERAMIC 1U Z 10V
C3809 403 283 6309 CERAMIC 1U Z 10V
C3811 403 283 6309 CERAMIC 1U Z 10V
C3812 403 162 6208 ELECT 1U M 50V
C3881 403 162 6208 ELECT 1U M 50V
C5003 403 323 8805 CERAMIC 2.2U Z 16V
C5004 403 323 8805 CERAMIC 2.2U Z 16V
C5006 403 323 8805 CERAMIC 2.2U Z 16V
C5007 403 323 8805 CERAMIC 2.2U Z 16V
C5008 403 323 8805 CERAMIC 2.2U Z 16V
C5009 403 323 8805 CERAMIC 2.2U Z 16V
C5011 403 323 1301 CERAMIC 0.47U Z 10V
C5012 403 323 1301 CERAMIC 0.47U Z 10V
C5013 403 304 3102 ELECT 22U M 16V
C5014 403 321 2607 ELECT 10U M 16V
C5016 403 323 1301 CERAMIC 0.47U Z 10V
C5204 403 164 0204 CERAMIC 0.1U Z 25V
C5207 403 283 6309 CERAMIC 1U Z 10V
C5208 403 283 6309 CERAMIC 1U Z 10V
A/V BOARD
SENSOR 1 BOARD
CONNECT BOARD
Key No. Part No. Description Key No. Part No. Description
