Sanyo PLC-XU106

Key No. Part No. Description Key No. Part No. Description
KB8-XU10600
Electrical Parts List
-84-
307 210 1923 DIODE 1SS400 TE-61
D6853 307 235 0816 DIODE 1SS387 TPL3
307 210 1923 DIODE 1SS400 TE-61
D6854 307 235 0816 DIODE 1SS387 TPL3
307 210 1923 DIODE 1SS400 TE-61
D6855 307 235 0816 DIODE 1SS387 TPL3
307 210 1923 DIODE 1SS400 TE-61
D7812 307 254 2716 DIODE CMS16
D7862 307 254 2716 DIODE CMS16
D8901 307 235 0816 DIODE 1SS387 TPL3
307 210 1923 DIODE 1SS400 TE-61
D8902 307 235 0816 DIODE 1SS387 TPL3
307 210 1923 DIODE 1SS400 TE-61
MISCELLANEOUS
FB3620 652 002 8531 INDUCTOR 330OHM, P
FB3621 652 002 8531 INDUCTOR 330OHM, P
FB3622 652 002 8531 INDUCTOR 330OHM, P
FB3624 652 002 8531 INDUCTOR 330OHM, P
FB3626 652 002 8531 INDUCTOR 330OHM, P
FB3627 652 002 8531 INDUCTOR 330OHM, P
FB602 652 002 8500 INDUCTOR 330OHM, P
FB603 652 002 8500 INDUCTOR 330OHM, P
FB604 652 002 8500 INDUCTOR 330OHM, P
FB605 652 002 8500 INDUCTOR 330OHM, P
FB606 652 002 8500 INDUCTOR 330OHM, P
FB607 652 002 8500 INDUCTOR 330OHM, P
FB8801 652 002 8531 INDUCTOR 330OHM, P
K10A 952 001 8571 SOCKET,D-SUB 15P
K10B 952 001 8601 SOCKET,D-SUB 15P
K10C 952 001 8601 SOCKET,D-SUB 15P
K20A 652 002 8135 PLUG,D-SUB 9P
K9602 645 093 6760 TRANS,PULSE
SC1021 945 076 3503 SURGE-ABSORBER
SC1022 945 076 3503 SURGE-ABSORBER
SC1023 945 076 3503 SURGE-ABSORBER
SC1027 945 076 3503 SURGE-ABSORBER
SC1028 945 076 3503 SURGE-ABSORBER
SC1029 945 076 3503 SURGE-ABSORBER
SC4001 945 076 3503 SURGE-ABSORBER
SC4002 945 076 3503 SURGE-ABSORBER
SC4003 945 076 3503 SURGE-ABSORBER
SC4004 945 076 3503 SURGE-ABSORBER
SC4006 945 076 3503 SURGE-ABSORBER
SC5608 945 076 3503 SURGE-ABSORBER
SW6800 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6801 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6802 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6803 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6804 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6806 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6807 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6808 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6810 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6811 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
X1331 945 088 7179 OSC,CRYSTAL 27.0MHZ
X2331 945 088 7179 OSC,CRYSTAL 27.0MHZ
X8802 945 083 7556 OSC,CRYSTAL 25.0MHZ
X9885 945 060 9900 OSC,CERAMIC 8.00MHZ
655 003 1211 ASSY,PWB,R/C
CAPACITOR
C2901 403 455 1012 CERAMIC 1U K 10V
303 433 1112 CERAMIC 1U K 10V
C2902 303 453 8719 CERAMIC 470P K 50V
303 453 9211 CERAMIC 470P K 50V
303 282 5118 CERAMIC 470P K 50V
C2903 303 358 3215 CERAMIC 10U K 6.3V
303 368 7319 CERAMIC 10U K 6.3V
RESISTOR
R2901 301 225 1814 MT-GLAZE 47 JA 1/16W
R2902 301 224 8814 MT-GLAZE 100 JA 1/16W
DIODE
D2901 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
MISCELLANEOUS
A2901 652 002 3352 UNIT,REMOCON,RECEIVER
655 003 2485 ASSY,PWB,TEMP KB8AC
CAPACITOR
C4833 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C4834 303 358 3215 CERAMIC 10U K 6.3V
303 370 0018 CERAMIC 10U K 6.3V
303 368 7319 CERAMIC 10U K 6.3V
RESISTOR
R4831 301 225 8110 MT-GLAZE 10 JA 1/16W
R4832 301 225 8110 MT-GLAZE 10 JA 1/16W
A2000 655 003 1204 ASSY,PWB,AV
CAPACITOR
C2001 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C3051 303 454 0910 CERAMIC 100P J 50V
C3061 303 454 0910 CERAMIC 100P J 50V
RESISTOR
R2001 301 260 4115 MT-GLAZE 75 JA 1/3W
R2002 301 224 8814 MT-GLAZE 100 JA 1/16W
R2008 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R2010 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R2012 301 260 4115 MT-GLAZE 75 JA 1/3W
R2022 301 260 4115 MT-GLAZE 75 JA 1/3W
R2051 301 150 5819 MT-GLAZE 100K JA 1/10W
R2052 301 150 5819 MT-GLAZE 100K JA 1/10W
R3001 301 150 5819 MT-GLAZE 100K JA 1/10W
R3011 301 150 5819 MT-GLAZE 100K JA 1/10W
R3021 301 224 8913 MT-GLAZE 100K JA 1/16W
R3031 301 150 5819 MT-GLAZE 100K JA 1/10W
R3051 301 150 5819 MT-GLAZE 100K JA 1/10W
R3061 301 255 6513 MT-GLAZE 100 JA 1/10W
R3063 301 150 5819 MT-GLAZE 100K JA 1/10W
R3064 301 255 6513 MT-GLAZE 100 JA 1/10W
