Sanyo PLC-XU106

Key No. Part No. Description Key No. Part No. Description
KB8-XU10600
-85-
Electrical Parts List
COIL
L2011 301 037 5017 MT-GLAZE 0.000 ZA 1/10W
L2021 301 037 5017 MT-GLAZE 0.000 ZA 1/10W
MISCELLANEOUS
K20A 945 068 3740 JACK,RCA-3
K20B 645 089 9041 SOCKET,DIN 4P
952 001 4740 SOCKET,DIN 4P
K30A 945 006 4792 JACK,PHONE D3.6
952 001 0070 JACK,PHONE D3.6
952 001 0971 JACK,PHONE D3.5
K30B 945 006 4792 JACK,PHONE D3.6
952 001 0070 JACK,PHONE D3.6
952 001 0971 JACK,PHONE D3.5
K30C 945 006 4792 JACK,PHONE D3.6
952 001 0070 JACK,PHONE D3.6
952 001 0971 JACK,PHONE D3.5
SC2001 945 076 3503 SURGE-ABSORBER
SC2011 945 076 3503 SURGE-ABSORBER
SC2021 945 076 3503 SURGE-ABSORBER
SC2051 945 076 3503 SURGE-ABSORBER
SC2052 945 076 3503 SURGE-ABSORBER
SC3001 945 076 3503 SURGE-ABSORBER
SC3011 945 076 3503 SURGE-ABSORBER
SC3021 945 076 3503 SURGE-ABSORBER
SC3031 945 076 3503 SURGE-ABSORBER
SC3051 945 076 3503 SURGE-ABSORBER
SC3061 945 076 3503 SURGE-ABSORBER
655 003 1198 ASSY,PWB SW
!SW901 945 063 5176 SWITCH,PUSH 2P-2TX3
655 003 1174 ASSY,PWB,POWER
TRANSISTOR
Q611 305 217 6600 TR 2SK3934
Q612 305 217 6600 TR 2SK3934
Q621 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q622 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q641 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q642 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q643 305 217 6600 TR 2SK3934
Q651 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q661 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC621 409 690 7918 IC FA5550N
IC631 309 653 7405 IC MR4010-7101
IC671 409 692 2515 IC TA76L431FB
CAPACITOR
C611 303 222 1326 CERAMIC 1000P K 1K
304 084 6300 CERAMIC 1000P K 1K
C612 303 222 1326 CERAMIC 1000P K 1K
304 084 6300 CERAMIC 1000P K 1K
C613 303 451 4119 MT-POLYEST 1U K 450V
C614 303 451 4119 MT-POLYEST 1U K 450V
C615 404 115 2704 ELECT 330U M 420V
404 115 6306 ELECT 330U M 420V
C621 303 336 3510 CERAMIC 0.47U K 16V
C622 304 091 4504 CERAMIC 0.047U K 50V
C623 304 090 1207 CERAMIC 0.01U K 50V
C625 304 090 1108 CERAMIC 1000P K 50V
C626 303 396 9613 CERAMIC 1U K 25V
403 478 5912 CERAMIC 1U K 25V
C627 304 091 3309 CERAMIC 2200P K 50V
C629 303 265 3216 CERAMIC 1000P J 50V
C631 303 157 4215 CERAMIC 220P J 50V
C632 303 245 4417 CERAMIC 470P K 2K
C633 303 265 3216 CERAMIC 1000P J 50V
C634 304 091 3309 CERAMIC 2200P K 50V
C641 304 091 2609 CERAMIC 0.1U K 50V
C644 303 417 9912 CERAMIC 4.7U K 25V
C651 303 411 1823 ELECT 220U M 35V
C653 303 370 1510 CERAMIC 0.1U K 50V
C661 303 445 4405 ELECT 1800U M 25V
C662 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C663 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C664 303 429 6718 ELECT 1500U M 10V
C665 303 409 9913 ELECT 470U M 16V
C671 304 091 2609 CERAMIC 0.1U K 50V
C672 303 410 7113 ELECT 100U M 25V
C673 303 410 7113 ELECT 100U M 25V
C674 403 477 6514 MT-POLYEST 0.01U J 630V
!C693 304 073 4508 CERAMIC 2200P K 250V
RESISTOR
R611 401 353 0311 MT-GLAZE 430K JA 1/3W
R612 401 353 0212 MT-GLAZE 360K JA 1/3W
R613 301 256 6314 MT-GLAZE 47K JA 1/10W
R614 402 109 8206 RESISTER 0.15 JB 5W
R615 301 188 3313 MT-GLAZE 680K JA 1/4W
R616 301 188 3313 MT-GLAZE 680K JA 1/4W
R617 301 256 6314 MT-GLAZE 47K JA 1/10W
