Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
3 Temp B-A Warning (High)
Temp. B-A to judge the Temp Error at
High (Clogging Det.)
100 100 100 100 0-100
4 Temp C-A Warning (High)
Temp. C-A to judge the Temp Error at
High (Clogging Det.)
100 100 100 100 0-100
5 Temp A Warning (Normal)
Temp. A to judge the Temp Error at
Normal (Room)
46 46 46 46 30-100
6 Temp B Warning (Normal)
Temp. B to judge the Temp Error at
Normal (Panel)
60 61 56 54 30-100
7 Temp C Warning (Normal)
Temp. C to judge the Temp Error at
Normal (Lamp)
65 65 63 63 30-100
8 Temp B-A Warning (Normal)
Temp. B-A to judge the Temp Error at
Normal (Clogging Det.)
100 100 100 100 0-100
9 Temp C-A Warning (Normal)
Temp. C-A to judge the Temp Error at
Normal (Clogging Det.)
100 100 100 100 0-100
10 Temp A Warning (Eco)
Temp. A to judge the Temp Error at
Eco (Room)
46 46 45 45 30-100
11 Temp B Warning (Eco)
Temp. B to judge the Temp Error at
Eco (Panel)
60 61 55 54 30-100
12 Temp C Warning (Eco)
Temp. C to judge the Temp Error at
Eco (Lamp)
65 64 62 62 30-100
13 Temp B-A Warning (Eco)
Temp. B-A to judge the Temp Error at
Normal (Clogging Det.)
100 100 100 100 0-100
14 Temp C-A Warning (Eco)
Temp. C-A to judge the Temp Error at
Normal (Clogging Det.)
100 100 100 100 0-100
15
Temp A Warning Offset
(Temp)
Offset of Temp Error (Temp.)
Error Setting Value is increased XC at
the below condition
* Standby
* Right to turn on the lamp
*Right to change the Lamp mode
5 0-100
16
Temp B Warning Offset
(Temp)
5 0-100
17
Temp C Warning Offset
(Temp)
15 0-100
18
Temp B-A Warning Offset
(Temp)
0 0-100
19
Temp C-A Warning Offset
(Temp)
0 0-100
20
Temp A Warning Offset
(Time)
Offset of Temp Error (Minutes)
Error Setting Value is increased X
minute at the below condition
* Standby
* Right to turn on the lamp
*Right to change the Lamp mode
5 0-100
21
Temp B Warning Offset
(Time)
5 0-100
22
Temp C Warning Offset
(Time)
18 0-100
23
Temp B-A Warning Offset
(Time)
1 0-100
24
Temp C-A Warning Offset
(Time)
1 0-100
25 Factory Mode For factor use 0 0-1
Group
254
Fan Control Range Setting (Temp./Voltage) Normal Ceiling
HiLand-
Normal
HiLand-
Ceiling
0 High Fan Control Min Temp
Temp Senser Control Start/End Temp.
at High
38 38 34 33 20-100
1 High Fan Control Max Temp 43 43 40 38 20-100
2 High Fan1 Min
Fan voltage value at High (unit: 0.1V)
85 85 105 105 0-255
3 High Fan1 Max 135 135 135 135 0-255
4 High Fan2 Min 85 85 110 110 0-255
5 High Fan2 Max 130 130 130 130 0-255
6 High Fan3 Min 75 75 100 100 0-255
7 High Fan3 Max 77 77 115 115 0-255
8 High Fan4 Min 9999 9999 -
9 High Fan4 Max 9999 9999 -
10
Normal Fan Control Min
Temp
Temp Senser Control Start/End Tem.
p at Normal
38 39 35 33 20-100
11
Normal Fan Control Max
Temp
43 43 40 38 20-100
12 Normal Fan1 Min
Fan voltage value at Normal (unit:
0.1V)
70 70 95 95 0-255
13 Normal Fan1 Max 125 125 125 125 0-255
14 Normal Fan2 Min 75 75 100 100 0-255
15 Normal Fan2 Max 120 120 120 120 0-255
16 Normal Fan3 Min 85 85 105 105 0-255
17 Normal Fan3 Max 85 85 110 110 0-255
18 Normal Fan4 Min 9999 9999 -
19 Normal Fan4 Max 9999 9999 -
20 Eco Fan Control Min Temp
Temp Senser Control Start/End Tem.
p at Eco
38 39 35 32 20-100
21 Eco Fan Control Max Temp 42 43 39 38 20-100
22 Eco Fan1 Min
Fan voltage value at Eco (unit: 0.1V)
60 60 95 95 0-255
23 Eco Fan1 Max 115 115 115 115 0-255
24 Eco Fan2 Min 68 68 90 90 0-255
25 Eco Fan2 Max 110 110 110 110 0-255
