-45-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
26 Eco Fan3 Min
Fan voltage value at Eco (unit: 0.1V)
53 53 58 58 0-255
27 Eco Fan3 Max 53 53 63 63 0-255
28 Eco Fan4 Min 9999 9999 -
29 Eco Fan4 Max 9999 9999 -
Group
255
Fan Start/Cooling Setting
0 Fan1 Initial Volt
Fan Start Voltage (0.1V)
70 0-255
1 Fan2 Initial Volt 70 0-255
2 Fan3 Initial Volt 70 0-255
3 Not used 9999 -
4 Fan1 Cooling Speed Fan Voltage at Power Off (0.1V) 130 0-255
5 Fan2 Cooling Speed 130 0-255
6 Fan3
Cooling Speed 130 0-255
7 Not used 9999 -
8 Cooling Time L1
Cooling Time stting at Fan Mode L1 (x
30 sec)
1: 30, 3: 90, 15: 450 sec.
2 1-15
9 Cooling Time L2
Cooling Time stting at Fan Mode L2 (x
30 sec)
1: 30, 3: 90, 15: 450 sec.
3 1-15
10 Temp Error Cooling Time
Cooling Time setting at Temp Erro (x
30 sec)
3 1-15
11
OnStart Cooling Start
Threshold
38 0-100
12 After shutdown cooling Cooling after shutdown (0: No, 1: Yes) 1 0-1
Group
256
Fan Lamp Voltage Down Setting
0 Lamp Voltage
Current Lamp Voltage (0.1V)(Read
only)
- 0-255
1 Lamp Vol Threshold
Threshold to judge Lamp Voltage
Down ( V×10)
30-90
2 Fan1 Speed Gain
Additional Fan Speed of Min at Lamp
Voltage Down (unit: 0.1V)
0-255
3 Fan2 Speed Gain 0-255
4 Fan3 Speed Gain 0-255
5 Not used 9999 0-255
Group
257
Fan Dimmer Setting
0
Dimmer Average Check
Period
Dimmer Avarage measurement Time
(0:10sec, 1:30sec, 2:6sec,
90sec...10:300sec)
1 0-10
1 Dimmer Average Dimmer Avarage Value (Read only) -
2 Last Voltage Difference -
3 Voltate Difference Goal
Group
258
Fan IC Temp for Netowrk model
0
Standby Cooling Check
Cycle
Temp A check cycle at Standby 5
1
Standby Cooling Start
Threshold
Cooling start threshold temp A 46
2 Standby Cooling Enable Cooling in standby Enable 1
Group
260
Auto Calibration (Commn) * Auto Calibration
0 Execute Calibration 0 0 - 1
Executes Auto-Calibration when
changiing the Value (PC White
100%)
1 Loop Count
Maximum Execution Times
(OFFSET->GAIN)
10 1 - 30
2 Auto Status
Result of Auto-Calibration (Last
Memory)
0 0 / 1 / 9
0: OK, 1: Adjusting,9: Error *
ReadOnly
3 AutoWait Wait Value for each setting 1 1 - 20
4 CHECK -Tolelance Torelance of OFFSET 2 1 - 255
Group
261
Auto Calibration (RGB)
0 OFFSET AREA H START
Black Level Acquiring Area H-Start
Position
975 0 - 1000
1 OFFSET AREA V START
Black Level Acquiring Area V-Start
Position
500 0 - 1000
2 GAIN AREA H START
White Level Acquiring Area H-Start
Position
25 0 - 1000
3 GAIN AREA V START
White Level Acquiring Area V-Start
Position
500 0 - 1000
