Page #96 background imageLoading...
Page #96 background image
Key No. Part No. Description Key No. Part No. Description
KC8-XU11600
Electrical Parts List
-96-
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6843 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6844 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6845 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
408 063 7507 ZENER DIODE MM3Z6V2B
D6850 307 235 0816 DIODE 1SS387 TPL3
307 210 1923 DIODE 1SS400 TE-61
D6851 307 235 0816 DIODE 1SS387 TPL3
307 210 1923 DIODE 1SS400 TE-61
D6852 307 235 0816 DIODE 1SS387 TPL3
307 210 1923 DIODE 1SS400 TE-61
D6853 307 235 0816 DIODE 1SS387 TPL3
307 210 1923 DIODE 1SS400 TE-61
D6854 307 235 0816 DIODE 1SS387 TPL3
307 210 1923 DIODE 1SS400 TE-61
D6855 307 235 0816 DIODE 1SS387 TPL3
307 210 1923 DIODE 1SS400 TE-61
D7812 307 254 2716 DIODE CMS16
D7862 307 254 2716 DIODE CMS16
D8081 307 254 2716 DIODE CMS16
D8082 307 210 1923 DIODE 1SS400 TE-61
D8091 307 254 2716 DIODE CMS16
D8092 307 235 0816 DIODE 1SS387 TPL3
307 210 1923 DIODE 1SS400 TE-61
D8093 307 235 0816 DIODE 1SS387 TPL3
307 210 1923 DIODE 1SS400 TE-61
D8094 307 235 0816 DIODE 1SS387 TPL3
307 210 1923 DIODE 1SS400 TE-61
MISCELLANEOUS
FB3620 945 086 6037 IMPEDANCE,330 OHM P
FB3621 945 086 6037 IMPEDANCE,330 OHM P
FB3622 945 086 6037 IMPEDANCE,330 OHM P
FB3624 945 086 6037 IMPEDANCE,330 OHM P
FB3626 945 086 6037 IMPEDANCE,330 OHM P
FB3627 945 086 6037 IMPEDANCE,330 OHM P
FB602 945 041 1978 INDUCTOR,330 OHM
FB603 945 041 1978 INDUCTOR,330 OHM
FB604 945 041 1978 INDUCTOR,330 OHM
FB605 945 041 1978 INDUCTOR,330 OHM
FB606 945 041 1978 INDUCTOR,330 OHM
FB607 945 041 1978 INDUCTOR,330 OHM
FB8801 945 086 6037 IMPEDANCE,330 OHM P
K10A 945 076 2698 SOCKET,DVI 29P
K10B 952 001 8601 SOCKET,D-SUB 15P
K20A 652 002 8135 PLUG,D-SUB 9P
K40A 952 001 8571 SOCKET,D-SUB 15P
K40C 645 095 2647 SOCKET,USB 4P
SC5201 945 076 3503 SURGE-ABSORBER
SC5202 945 076 3503 SURGE-ABSORBER
SC5203 945 076 3503 SURGE-ABSORBER
SC5608 945 076 3503 SURGE-ABSORBER
SW6800 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6801 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6802 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6803 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6804 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6806 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6807 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6808 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6810 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
SW6811 945 026 2792 SWITCH,PUSH 1P-1TX1
952 001 8830 SWITCH,PUSH 1P-1TX1
X1331 945 088 7179 OSC,CRYSTAL 27.0MHZ
X1801 645 092 8857 OSC,CRYSTAL 48MHZ
X2331 945 088 7179 OSC,CRYSTAL 27.0MHZ
X8001 645 102 6934 OSC,CRYSTAL 27.000MHZ
X9885 945 060 9900 OSC,CERAMIC 8.00MHZ
655 003 3352 ASSY,PWB,R/C
CAPACITOR
C2901 403 455 1012 CERAMIC 1U K 10V
303 433 1112 CERAMIC 1U K 10V
C2902 303 453 8719 CERAMIC 470P K 50V
303 453 9211 CERAMIC 470P K 50V
303 282 5118 CERAMIC 470P K 50V
C2903 303 358 3215 CERAMIC 10U K 6.3V
303 370 0018 CERAMIC 10U K 6.3V
303 368 7319 CERAMIC 10U K 6.3V
RESISTOR
R2901 301 225 1814 MT-GLAZE 47 JA 1/16W
R2902 301 224 8814 MT-GLAZE 100 JA 1/16W
DIODE
D2901 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
D6834 307 209 7513 LED SML-210YT T86 L
MISCELLANEOUS
A2901 645 102 3773 UNIT,REMOCON RECEIVER
655 003 3345 ASSY,PWB,TMP
CAPACITOR
C4833 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C4834 303 358 3215 CERAMIC 10U K 6.3V
303 370 0018 CERAMIC 10U K 6.3V
303 368 7319 CERAMIC 10U K 6.3V
RESISTOR
R4831 301 225 8110 MT-GLAZE 10 JA 1/16W
R4832 301 225 8110 MT-GLAZE 10 JA 1/16W
A2000 655 003 3321 ASSY,PWB,AV
CAPACITOR
C2003 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C3051 303 454 0910 CERAMIC 100P J 50V
C3061 303 454 0910 CERAMIC 100P J 50V
