Sanyo PLC-XU116 Service Manual

Key No. Part No. Description Key No. Part No. Description
KC8-XU11600
-97-
Electrical Parts List
RESISTOR
R2001 301 260 4115 MT-GLAZE 75 JA 1/3W
R2002 301 224 8814 MT-GLAZE 100 JA 1/16W
R2008 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R2010 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R2012 301 260 4115 MT-GLAZE 75 JA 1/3W
R2022 301 260 4115 MT-GLAZE 75 JA 1/3W
R2051 301 150 5819 MT-GLAZE 100K JA 1/10W
R2052 301 150 5819 MT-GLAZE 100K JA 1/10W
R3001 301 150 5819 MT-GLAZE 100K JA 1/10W
R3011 301 150 5819 MT-GLAZE 100K JA 1/10W
R3021 301 150 5819 MT-GLAZE 100K JA 1/10W
R3031 301 150 5819 MT-GLAZE 100K JA 1/10W
R3051 301 150 5819 MT-GLAZE 100K JA 1/10W
R3061 301 255 6513 MT-GLAZE 100 JA 1/10W
R3063 301 150 5819 MT-GLAZE 100K JA 1/10W
R3064 301 255 6513 MT-GLAZE 100 JA 1/10W
COIL
L2011 301 037 5017 MT-GLAZE 0.000 ZA 1/10W
L2021 301 037 5017 MT-GLAZE 0.000 ZA 1/10W
MISCELLANEOUS
K20B 645 089 9041 SOCKET,DIN 4P
952 001 4740 SOCKET,DIN 4P
K20F 945 006 4792 JACK,PHONE D3.6
952 001 0070 JACK,PHONE D3.6
952 001 0971 JACK,PHONE D3.5
K30A 945 006 4792 JACK,PHONE D3.6
952 001 0070 JACK,PHONE D3.6
952 001 0971 JACK,PHONE D3.5
K30B 945 006 4792 JACK,PHONE D3.6
952 001 0070 JACK,PHONE D3.6
952 001 0971 JACK,PHONE D3.5
K30C 945 006 4792 JACK,PHONE D3.6
952 001 0070 JACK,PHONE D3.6
952 001 0971 JACK,PHONE D3.5
K40A 945 068 3740 JACK,RCA-3
SC2001 945 076 3503 SURGE-ABSORBER
SC2011 945 076 3503 SURGE-ABSORBER
SC2021 945 076 3503 SURGE-ABSORBER
SC2051 945 076 3503 SURGE-ABSORBER
SC2052 945 076 3503 SURGE-ABSORBER
SC3001 945 076 3503 SURGE-ABSORBER
SC3011 945 076 3503 SURGE-ABSORBER
SC3021 945 076 3503 SURGE-ABSORBER
SC3031 945 076 3503 SURGE-ABSORBER
SC3051 945 076 3503 SURGE-ABSORBER
SC3061 945 076 3503 SURGE-ABSORBER
655 003 3314 ASSY,PWB,SW
SW901 945 063 5176 SWITCH,PUSH 2P-2TX3
PACKING MATERIALS
610 347 4311 CARTON CASE-KC8AC
610 340 0273 POLY BAG-PT5EC
610 336 8221 CUSHION SPACER -KB3AC
610 339 5463 CUSHION -KB3AC
655 002 4824 INSTALLATION SHEET KF3AC
ACCESSORIES
OWNER'S MANUAL
610 349 2452 CD-ROM(NETWORK V&C5)
610 348 3511 CD-ROM,OWNERS MANUAL-KC8AC
655 003 3475 SAFETY MANUAL-KG5AC
655 003 3154 USB MEMORY MANUAL-KY7AC
655 003 3499 SETUP INST-KC8AC
AC CORD
!US 945 064 6363 CORD,POWER-3.0MK,US
 !EU 945 054 1155 CORD,POWER-3.0MK
 !UK 945 054 1148 CORD,POWER-3.318MK
!BRA 645 102 6996 CORD,POWER-2.5MK,BRA
REMOTE CONTROL
645 100 0880 ASSY,REMOCON MXAV
910 319 1820 RC-BATTERY LID-CXSP
MISCELLANEOUS
610 338 0223 STRAP CAP-KB3AC
610 344 8442 BOX_USB-KG5AC
610 336 8405 CARRY BAG-KB3AC
610 342 8024 CARRY BAG-KL6A
610 345 5594 SPACER MAGIC USB-KG5AC
945 073 4855 CABLE,INTERFACE VGA
645 093 1642 CABLE,INTERFACE VGA
410 704 3700 USB,MEMORY STICK 512M
PROJECTOR SERVICE TOOL
610 343 5596 CD-ROM,PJ SVC TOOL V420
