-28-
Electrical Adjustments
Item No. NAME Device
XGA
Range Description
PC/DVI/HDCP
Component Video
HDTV 480p 480i NTSC PAL
32 DLYCTL uPD64012 8
33 OUTBITW uPD64012 0
34 CLKOINV uPD64012 1
35 RDOSEL uPD64012 0
36 SQCBCR uPD64012 0
37 ACTVH uPD64012 128
38 HPOSI uPD64012 128
39 HSPOS uPD64012 132
40 HSWID uPD64012 64
41 FSTAV uPD64012 0
42 VSPOS uPD64012 64
43 VSWID uPD64012 2
44 VBKFAL uPD64012 260
45 VBKRIS uPD64012 16
46 INBKENA uPD64012 0
47 YBLK uPD64012 0
48 SYNCSEL uPD64012 1
49 VDSEL uPD64012 1
50 HSPOL uPD64012 1
51 VSPOL uPD64012 1
52 FIELDPOL uPD64012 1
53 INHBKST uPD64012 715
54 INHBKEN uPD64012 853
55 INVBLKST uPD64012 260
56 INVBLKEN uPD64012 16
57 FLDTHR uPD64012 0
58 FILDIV uPD64012 0
59 TSRTCNV uPD64012 1
VIDEO
NTSC/PAL
S-VIDEO
NTSC/PAL
YCBCR
480i/575i
SCART
480i/575i
60 R_GAIN uPD64012 22 22 22 10
61 G_GAIN uPD64012 22 22 22 17
62 B_GAIN uPD64012 22 22 22 10
63 FLTSEL uPD64012 0
64 PEDIIRS2 uPD64012 0
65 SBCNT2 uPD64012 32
66 CBGAIN uPD64012 32
67 CRGAIN uPD64012 32
68 YGCAUTO uPD64012 0
69 YGCVAL uPD64012 58
70 YGCOFF uPD64012 0
71 YGCMVS uPD64012 0
72 YPGAINS uPD64012 2
73 YGCAVAL uPD64012 9
74 MAXIIRS uPD64012 0
75 PEDIIRS uPD64012 0
76 YGCMODE1 uPD64012 0
77 YGCMODE2 uPD64012 0
78 YGCIIRS uPD64012 1
79 YCSV uPD64012 0
80 YCOMA uPD64012 2
81 YCOMB uPD64012 2
82 YCSHY uPD64012 0
83 YCSHC uPD64012 0
84 COBPFOFF uPD64012 0
85 YCSCOF uPD64012 4
86 YCSSY uPD64012 0
87 VLTYPE uPD64012 1
88 YCSSC uPD64012 0
89 VAPONV uPD64012 0
90 VAPG uPD64012 4
91 VAPI uPD64012 16
92 PALCFIL uPD64012 0
93 YCSY2F uPD64012 3
94 TRF uPD64012 0
95 TRGAIN uPD64012 0
96 TRPAL uPD64012 0
97 APCGAIN uPD64012 1
98 ACCGAIN uPD64012 1
99 ACCLIM uPD64012 8
100 STNTSCM uPD64012 0
101 STPALD uPD64012 0
VIDEO S-VIDEO YCBCR SCART
NTSC / PAL NSTC / PAL 480i / 575i 480i / 575i
102 SBCNT uPD64012 109 / 111 106 / 108 119 / 118 118 / 118
103 SBCLRU uPD64012 128 128 128 141
104 SBCLRV uPD64012 128 128 128 141
105 YCONR uPD64012 0
106 CCONR uPD64012 0
107 YCORB uPD64012 0
To Next Page
