MY5-XU8600
-57-
Electrical Parts List
-57-
ASSEMBLIED BOARDS
! 610 321 9677 ASSY,PWB,SUB-POWER MS5A
! 610 326 1836 ASSY,PWB,LINE FILTER MT5A
! 610 327 8841 ASSY,PWB,POWER MW5A
! 610 326 1942 ASSY,PWB,R/C. MW5A
! 610 325 9031 ASSY,PWB,MAIN MY5A
OUT OF CIRCUIT BOARD
!L901 645 003 3834 CORE,FERRITE
!LF901 645 078 6471 UNIT,NOISE FILTER
!LP900 610 323 0726 COMPL,OPTICAL LAMP MT5A
!A901 645 076 4790 UNIT,BALLAST
A901A 610 322 7092 CABLE,BALLAST MS5A
!FN901 645 054 9120 MOTOR,FAN DC 2.64W
!FN902 645 079 7194 MOTOR,FAN DC 1.92W
!FN903 645 062 3103 MOTOR,FAN DC 3.6W
!FN904 645 062 3103 MOTOR,FAN DC 3.6W
!FN905 645 062 3103 MOTOR,FAN DC 3.6W
!FN906 645 078 5665 MOTOR,FAN DC 1.56W
SP901 645 078 6105 SPEAKER,8
SP901A 610 323 6766 HOLDER SPEAKER-MT5A
!SW902 645 079 2526 SWITCH,THERMAL(105DEG)
WK8D-28D 645 053 2566 CORD,ID CONNECTOR
610 321 9677 ASSY,PWB,SUB-POWER MS5A
TRANSISTOR
Q7801 405 128 9615 TR 2SC2411K-T146-Q
Q7802 405 128 9615 TR 2SC2411K-T146-Q
CAPACITOR
C7801 404 102 7200 DL-ELECT 0.47F Z 11V
RESISTOR
R7801 401 162 3619 MT-GLAZE 470 JA 1/10W
R7802 401 102 7615 MT-GLAZE 27 JA 1W
R7803 401 152 3216 MT-GLAZE 330 JA 1/10W
R7804 401 102 7516 MT-GLAZE 22 JA 1W
DIODE
D7801 407 208 9713 ZD UDZS-TE-175.6B
D7802 407 208 9713 ZD UDZS-TE-175.6B
D7803 407 210 5413 DIODE RB551V-30-TE-17
D7804 407 209 1211 ZD UDZS-TE-176.2B
D7806 407 210 5413 DIODE RB551V-30-TE-17
610 326 1836 ASSY,PWB,LINE FILTER MT5A
CAPACITOR
!C601 404 104 9608 MT-POLYEST 0.22U K 275V
404 104 9707 MT-POLYEST 0.22U M 275V
!C602 404 104 9608 MT-POLYEST 0.22U K 275V
404 104 9707 MT-POLYEST 0.22U M 275V
RESISTOR
!R601 401 287 9015 MT-GLAZE 470K JA 1W
!R602 401 287 9015 MT-GLAZE 470K JA 1W
VARIABLE RESISTOR
!VA601 408 018 9808 VARISTOR ENC471D-14AS
COIL
!L601 645 050 2231 LINE FILTER
MISCELLANEOUS
!F601 423 021 7801 FUSE 250V 6.3A
SW901 645 063 8077 SWITCH,PUSH 2P-2TX3
610 327 8841 ASSY,PWB,POWER MW5A
TRANSISTOR
Q601 405 134 5925 TR 2SA1037AK-T146-R
405 147 2215 TR 2SA1037AK-S-T146
405 002 0318 TR 2SA1037K T146 R
405 002 0417 TR 2SA1037K T146 S
405 002 6726 TR 2SA1179-M6-TB
405 002 6924 TR 2SA1179-M7-TB
405 163 1513 TR 2SA1179N-M6-TB
405 173 9615 TR 2SA1235A1E
405 173 9714 TR 2SA1235A1F
Q602 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q611 405 140 3704 TR 2SK2698
Q621 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q622 405 134 5925 TR 2SA1037AK-T146-R
405 147 2215 TR 2SA1037AK-S-T146
405 002 0318 TR 2SA1037K T146 R
405 002 0417 TR 2SA1037K T146 S
405 002 6726 TR 2SA1179-M6-TB
405 002 6924 TR 2SA1179-M7-TB
405 163 1513 TR 2SA1179N-M6-TB
405 173 9615 TR 2SA1235A1E
405 173 9714 TR 2SA1235A1F
Q642 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q643 405 211 5804 TR 2SK3561
Q651 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
405 173 9813 TR 2SC3928A1R
Key No. Part No. Description Key No. Part No. Description
Electrical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
