-31-
Electrical Adjustments
Item No. NAME Device
XGA
Range Description
PC/DVI/HDCP
Component Video
HDTV 480p 480i NTSC PAL
120 B_MAX L3E7072K0A 695
121 G_V1 (DAC) M62398FP 100
122 R_V1 (DAC) M62398FP 100
123 B_V1 (DAC) M62398FP 100
124 REF_G (DAC) M62398FP 203
125 REF_R (DAC) M62398FP 203
126 REF_B (DAC) M62398FP 198
127 G_LCCOM (L3E06100) L3E6100 105
128 R_LCCOM (L3E06100) L3E6100 105
129 B_LCCOM (L3E06100) L3E6100 105
130 SyncPosition L3E7072K0A 0 Link with 9-131
131 SyncVideoPosition L3E7072K0A 0 Link with 9-130
132 Color Shading SW L3E7072K0A 1 Color Shading Correction, 0: Off, 1: On (Not memorized)
Group 100 OPTION (Lamo Time, Service Port etc)
1 RS232C Baudrate PW186 0 0: 19200bps 1: 9600bps
2 PJLink Enable MCI 1 0: Disable, 1: Enable
5 PW Debug Command Enable PW186 0 0:Disable 1:Enable(Sanyo Serial Command Disable)(Not memorized)
6 Device Refresh Disable PW186 0 0:Enable 1:Disable(Not memorized)
20 Projector Time Reset PW186 0 0-20 Resets Projector time when the value is set to 10.
21 Lamp Warning Time (NORMAL) PW186 1000 0-10000 Normal lamp warning time
22 Lamp Warning Time (ECO) PW186 2000 0-10000 Eco lamp warning time
31 Lamp life test enable 0 0: Disable, 1: Enable
32 Lamp On Time (for test purpose) 1
33 Lamp Off Time (for test purpose) 3
Group 101 OPTION (Signal Processing)
0
1
2 Shoot Out Mode PW186 0 1: Shoot Out Mode Enable0: Disable
3 Frame Lock SW PW186 0 0:Not V-Sync, 1:V-Sync
4
5 Non Brand PW186 0 0:Normal1:Non Brand
6 Monitor Error Count PW186 5 Threshold value of Monitor error count
7 CABLE SW PW186 0 Cable switch
8 1080i 422 Enable PW186 0 1: Store data witn 422 into PW memory
9 SXGA Interlace 422 Enable PW186 1 1: Store data witn 422 into PW memory
Group 102 Auto keystone
0 Offset PW186 0
-1056~1056
Indicates with 1/64 degrees
1 Offset Switch PW186 0 0 ~ 1 0: Normal, 1: Caliblation error
2 Degug Mode PW186 0 0 ~ 1 0: No display, 1: Angle(0.5), AD(1/1000), RS232C output
3 Service Calibration PW186 0 0 ~ 5 Service Calibration Execution , Press Select Key at Data 5
4 Lock Count PW186 5 1 ~ 255
5 Delta Vart Result PW186 64 1 ~ 255
6 Angle 1 Count PW186 1 1 ~ 10
7 Angle 2 Count PW186 5 1 ~ 10
8 Blind Sector 1 PW186 160 0 ~ 1024
9 Blind Sector 2 PW186 32 0 ~ 1024
10 Blind Sector 3 PW186 61 0 ~ 1024
Group 103 PW186 Image Control
PC COMPONENT VIDEO
PC/DVI/HDCP
HDTV 480i VIDEO SCART
0 Center Contrast PW186
512/512/512
512 512 512 512 PW186 CONTRAST Center adjustment
1 Center Brightness PW186
512/512/512
512 512 512 512 PW186 BRIGHTNESS Center adjustment
2 Center Color PW186
512/512/512
475 475 475 425 PW186 COLOR Center adjustment
3 Center Tint PW186 90/90/90 82 82 82 82 PW186 TINT Center adjustment
4 Center Sharpness PW186 16/16/16 16 16 16 16 PW186 SHARPNESS Center adjustment
5 Alpha Contrast PW186 40/40/40 40 40 40 40 PW186 CONTRAST Range adjustment
6 Alpha Brightness PW186
140/140/140
140 140 140 140 PW186 BRIGHTNESS Range adjustment
7 Alpha Color PW186 70/70/70 70 70 70 70 PW186 COLOR Range adjustment
8 Alpha Tint PW186 10/10/10 10 10 10 10 PW186 TINT Range adjustment
9 Alpha Sharpness PW186 10/10/10 10 10 10 10 PW186 SHARPNESS Range adjustment
Group 104 PW186 Auto PC Adjust Control
0 AutoPCAdjustEnable PW186 0 0-1 0:Auto1:Prohibit Auto PC Adj.
1 Frequency Step PW186 2 0-3
2 Frequency Threshold PW186 5 0-10
3 Fine Phase PW186 1 0-1
4 BLKDET PW186 1 0-3 Black Level Detecte Area
5 PHASEMSK PW186 0 0-3
Phase Detection Filter0:Effect all bits1:Disable lower 1 bit2:Disable lower 2
bits 3:Disable lower 3 bits
Group 105 Custom Mode
0 Connecting to H/V PW186 0 0-1 Link H and V, 1: On, 0: Off
1 Vertical Scaler PW186 100 0-200 Vertical Scaler Edit (Unit %)
2 Vertical Position PW186 100 0-200 Vertical Position Correction (Unit %)
3 RESET/STORE PW186 0 0-1 Reset Vertical Aspect 0:Reset, 1:Save0
4 Horizontal Scaler PW186 100 0-200 Horizontal Scaler Edit (Unit %)
5 Horizontal Position PW186 100 0-200 Horizontal Position Correction (Unit %)
6 RESET/STORE PW186 0 0-1 Reset Horizontal Aspect 0:Reset, 1:Save0
7 CUSTOM ON/OFF PW186 0 0-1 Custom function On/Off 1: On, 0:Off
Group 110 Dimmer Processing for Ballast type
0 DIMMER_CTRL_LEVEL1 PW186 14 Luminance Level1:Dimmer Level1 when less than the value. Link with 100-7
1 DIMMER_CTRL_LEVEL2 PW186 27 Luminance Level2:Dimmer Level2 when less than the value.
