10
Top Control
DJ8
E
G L H <
< INFO. button
Display the input source information (p.43).
G INPUT button
Select an input source (p.24).
8 LAMP REPLACE indicator
Lights yellow light when the projection lamp reaches its
end of life (pp.49, 53).
J WARNING indicator
– Lights red light when the projector detects an abnormal
condition.
– Blinks red when the internal temperature of the
projector exceeds the operating range (pp.44, 53).
H OK button
Execute the item selected or use it to access the
submenu items (p.20).
L POINT ! buttons
Select an item or adjust the setting values in the On-
Screen Menu.
E MENU button
Open or close the On-Screen Menu (p.20).
D
POWER indicator
– Lights red while the projector is in stand-by mode.
– Lights green during operations.
– Blinks red during the cooling-off period.
– Blinks green in the Power management mode (p.41).
– Blinks orange when the automatic slide shutter is
closed during operations (p.53).
Part Names and Functions
B
B POWER ON/STAND-BY button
Turn the projector on or off (pp.18, 19).
To Next Page
