8
Bottom
Back
Adjustable Feet
RGB Panel Cleaning Hole Cover
Terminals and Connectors
Main On/Off Switch
Power Cord Connector
Air Intake Vent
Lamp Cover
@ Kensington Security Slot
This slot is for a Kensington lock used to deter theft of
the projector.
*Kensington is a registered trademark of ACCO Brands Corporation.
D Exhaust Vent
Front
D
8 E LG H B
J Top Controls and Indicators
8 Automatic Slide Shutter
E Projection Lens
G Focus Ring
L Zoom Lever
H Infrared Remote Receiver
< Vertical Lens Shift Ring (Up/Down)
B Horizontal Lens Shift Ring (Left/Right)
Lens Shift Lock
<
Air flow
CAUTION
Hot air is exhausted from the exhaust vent.
Do not put heat-sensitive objects near this
side.
Part Names and Functions
J
