RATING CAPACITY: 12,000 BTU/h AIR FLOW RATE: 410 CFM
EVAPORATOR CONDENSER
ENT. TEMP. °F (°C) AMBIENT TEMP. °F (°C)
W.B. D.B. 75 85 95 105 115
(23.9) (29.4) (35.0) (40.6) (46.1)
TC 12,160 11,570 10,900 10,140 9,300
CI 0.78 0.85 0.93 1.07 1.21
72 (22.2) SHC 9,230 8,940 8,610 8,260 7,870
59 76 (24.4) SHC 10,500 10,210 9,890 9,530 9,140
(15.0) 80 (26.7) SHC 11,820 11,540 10,900 10,140 9,300
84 (28.9) SHC 12,160 11,570 10,900 10,140 9,300
88 (31.1) SHC 12,160 11,570 10,900 10,140 9,300
TC 12,610 12,050 11,450 10,760 10,020
CI 0.79 0.86 0.94 1.08 1.23
72 (22.2) SHC 7,700 7,450 7,180 6,880 6,570
63 76 (24.4) SHC 8,970 8,720 8,450 8,150 7,840
(17.2) 80 (26.7) SHC 10,300 10,050 9,780 9,480 9,160
84 (28.9) SHC 11,570 11,320 11,050 10,750 10,020
88 (31.1) SHC 12,610 12,050 11,450 10,760 10,020
TC 13,090 12,580 # 12,000 11,360 10,670
CI 0.79 0.87 0.95 1.1 1.24
72 (22.2) SHC 6,170 5,960 5,720 5,470 5,200
67 76 (24.4) SHC 7,440 7,230 7,000 6,740 6,470
(19.4) 80 (26.7) SHC 8,770 8,560 8,320 8,070 7,800
84 (28.9) SHC 10,040 9,830 9,590 9,340 9,070
88 (31.1) SHC 11,310 11,100 10,860 10,610 10,340
TC 13,790 13,310 12,790 12,230 11,600
CI 0.8 0.88 0.96 1.11 1.26
72 (22.2) SHC 4,640 4,460 4,270 4,070 3,840
71 76 (24.4) SHC 5,910 5,730 5,540 5,340 5,110
(21.7) 80 (26.7) SHC 7,240 7,060 6,870 6,660 6,440
84 (28.9) SHC 8,510 8,330 8,140 7,930 7,710
88 (31.1) SHC 9,780 9,600 9,410 9,210 8,980
TC 14,060 13,610 13,130 12,580 11,990
CI 0.82 0.89 0.98 1.13 1.28
75 76 (24.4) SHC 4,280 4,130 3,970 3,790 3,600
(23.9) 80 (26.7) SHC 5,610 5,460 5,300 5,120 4,920
84 (28.9) SHC 6,880 6,730 6,570 6,390 6,200
88 (31.1) SHC 8,150 8,000 7,840 7,660 7,470
TC : Total Cooling Capacity (BTU/h)
SHC: Sensible Heat Capacity (BTU/h)
CI : Compressor Input (kW)
Rating conditions are M.R.= 3.36 US pints/h
: Outdoor Ambient Temp. 95°F DB
: Indoor Unit Entering Air Temp. 80°F DB / 67°F WB
