2-1-3. Heat Pump Type (230/208 V)
Model Number
Heater class 2.55 kW STW0622H2 STW0922H2 STW1222H2 STW1522H2
3.45 kW STW0623H2 STW0923H2 STW1223H2 STW1523H2
5.00 kW STW0925H2 STW1225H2 STW1525H2
Voltage (V) 230 / 208
Performance HEAT PUMP
Cooling capacity BTU/h 7,100 / 7,000 9,000 / 8,800 12,000 / 11,800 14,000 / 13,800
(kW) (2.08 / 2.05) (2.64 / 2.58) (3.52 / 3.46) (4.1 / 4.04)
Heat pump capaciity BTU/h 6,400 / 6,200 8,100 / 8,000 10,800 / 10,600 13,300 / 13,200
(kW) (1.88 / 1.82) (2.37 / 2.34) (3.16 / 3.11) (3.9 3.87)
Air Flow....Hi CFM 315 / 285 315 / 285 410 / 370 410 / 370
(CMH) (535 / 484) (535 / 484) (697 / 629) (697 / 629)
Dehumidification Pints/h 2.3 2.8 3.8 3.8
Electrical Rating
Available voltage range V 253 to 187
Cooling Amperes A 2.7 / 2.9 3.5 / 3.8 4.9 / 5.3 6.6 / 7.2
Watts W 610 / 600 790 / 770 1,100 / 1,080 1,490 / 1,470
Power factor % 98 / 99 98 / 97 98 / 98 98 / 98
EER BTU/hW 11.6 / 11.6 11.4 / 11.4 10.9 / 10.9 9.4 / 9.4
Starting amperes A 17 22 29 41
Heat pump Amperes A 2.5 / 2.7 3.3 / 3.6 4.5 / 4.9 6.0 / 6.6
Watts W 570 / 550 740 / 730 1,020 / 1,000 1,350 / 1,340
COP W/W 3.3 / 3.3 3.2 / 3.2 3.1 / 3.1 2.9 / 2.9
Features
Controls / Temperature control Mechanical / Themostat
Control unit
Timer
Fan speeds 2
Airflow direction (Indoor) Horizontal Manual
Vertical
Air filter Washable
Air exhaust Yes
Compressor Rotary (Hermetic)
R22-Amount charged at shipment OZ 26.8 30.0 32.1 33.5
Refrigerant control Capillary Tube
Operation sound Indoor : Hi / Lo dB-A 44 / 42 47 / 45
Outdoor dB-A 60 61
Dimensions & Weight
Unit dimensions Height In 15-15/16
(Refer to page 11) Width In 41-1/8
Depth In 21-1/2
Package dimensions Height In 18-3/16
Width In 44-7/8
Depth In 24-7/8
Weight Net lbs 95 100 110 110
Shipping lbs 110 115 125 125
Shipping volume Cu Ft 11.7
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Electric Heating Specifications
Electric Heating
Model number STW0622C2 STW0623C2
STW0922C2 STW0923C2 STW0925C2
STW1222C2 STW1223C2 STW1225C2
STW1522C2 STW1523C2 STW1525C2
Heater class kW 2.55 3.45 5.00
Capacity BTU/h 8,600 / 7,100 11,700 / 9,600 17,000 / 13,900
Electrical rating Amperes A 11.1 / 10.4 15.5 / 14.0 22.4 / 20.2
Watts W 2,550 / 2,090 3,450 / 2,820 5,000 / 4,090
Recommended circuit protection A 15 20 30
Cord plug and wall outlet Tandem Perpendicular Large Tandem
230/208 V 15AMP 230/208 V 20AMP 230/208 V 30AMP
