Sanyo SUPER BL PY - External Views; Servo Amplifier

9. SPECIFICATIONS
9－116
9.4 External Views
9.4.1 Servo Amplifier
Servo Amplifier model numbers: PY2A015A2 • PY2A015A3
PY2A015H2 • PY2A015H3
PY2A015P2 • PY2A015P3
2. Mounting panel warking drawing
Front-side mounting
1. Earth terminal screw : M4
Rear-side mounting
The design of the main
nameplate may change
4. Body material : SPCC / green chromated
5. Warning label
3. Main nameplate
when the device meets
Tightening torque : 1.18N m
(front-mountable)
Notes :
other standards.
188
172min.
54min.
25
188
25
4-M4 4-M4
U
V
W
N
P
Y
188 168 198
R
S
T
t
r
5
15
25
5
50
2
70max.
2
130
2
Note 5
Note 1
UP
installation
Direction of
Note 5
Note 2
nameplate
Main
2
