3. SERVO SYSTEM CONFIGURATION
3－7
Connector List for PY2E (100 VAC input type)
Application Model No. Set contents Maker Maker’s model No.
Single item AL-00329461-02 CNA plug Phoenix Contact MSTB2.5/4-STF-5.08
10150-3000VE
10350-52A0-008
10120-3000VE
10320-52A0-008
MSTB2.5/4-STF-5.08
IC2.5/3-STF-5.08
PY2E015 and
PY2E030 (without
RDY output) set
AL-00397841
CN1 or CN2 plug
and housing
CNA, CNB or CND
plug
Sumitomo 3M
Phoenix Contact
IC2.5/4-STF-5.08
PY2E015 and
PY2E030
(with RDY output)
set
AL-00397841
AL-00329460-01
CN1 or CN2 plug
and housing
CNA, CNB, CNC or
CND plug
Sumitomo 3M
Phoenix Contact
PY2A015 (built-in
Regenerative resistor)
PY2A030
(built-in
Regenerative resistor)
(without RDY output)
set
AL-00329461-02
AL-00329458-01
AL-00292309
CN1 or CN2 plug
and housing
CNA or CNB plug
Sumitomo 3M
Phoenix Contact
PY2A015 (built-in
Regenerative resistor)
PY2A030
(built-in
Regenerative resistor) (with
RDY output) set
AL-00329461-02
AL-00329458-01
AL-00329460-01
AL-00292309
CN1 or CN2 plug
and housing
CNA, CNB or CNC
plug
Sumitomo 3M
Phoenix Contact
● Remote operator
Connected to the Servo Amplifier to set various parameters or check the internal status.
Model No.
RP-001
• Although a commercially available plug not listed in the above table may be used, it may
not engage with the amplifier properly depending on its shape.
• Consult with us when using a plug or housing whose engagement with the amplifier is not
confirmed.
• The power supply input connector CNA models differ depending on the input power
supply voltage type (200 VAC or 100 VAC input).
• CND connector (IC2.5/4-STF-5.08) is normally attached to Servo Amplifier having an
amplifier capacity of 50 A.
• CND connector (IC2.5/4-STF-5.08) is normally attached to 15A and 30A Servo Amplifier
with built-in regenerative resistor.
