141 English
OTHER DEVICES AND CONNECTIONS
DOCKING STATION
CONNECT THE DOCKING STATION
Set your camera in the supplied docking station to recharge the battery pack
as well as for easy connection to a computer, printer or TV. A remote control
unit is provided for even easier operation of your docked camera (playback
only).
CAUTION
Gently connect and disconnect the cable
i When connecting and disconnecting the cable, please do so with a gentle
touch. Exerting a strong pull on the cable or connector may damage them.
1 Use the supplied AC adaptor/
charger to connect the DC IN
terminal on the docking station to a
power outlet.
2 Connect the supplied power cord to
the AC adaptor/charger socket.
3 Plug the power cord into an
electrical outlet.
DC output plug
To DC IN terminal
The [n] mark on
the plug should be
facing down.
AC adaptor/Charger
Supplied power cord
AC adaptor/Charger
socket
To p o w e r
outlet
