10 Operating Instructions Stainless Steel In-Line Filter Holder Type 16274
Device Description
3 Device Description
3.1 Device Overview
Fig. 1: Stainless steel pressure filtration device
Pos. Designation Description
1 Upper part of device With lasered data (order number, serial number, pressure, volume)
2 O-ring Silicone
3 Backflow prevention device PTFE coated
4 Filter support PTFE coated
5 O-ring Silicone
7
8
9
1
2
3
4
5
6
