15
3.3.9 Additional functions used in conjunction with the main mode,
ADV in right soft key
1. Tracker (Pipetting, Rev. Pipetting, Multi Dispensing)
Tracker is a helpful feature for microplate dispensing and a unique feature
only available in Picus. Activate the Tracker in main modes ADV menu (right
soft key) by using the adjustment wheel to scroll on the Tracker and press the
operating button to activate the Tracker.
Tracker ON = Tracker is currently OFF and pressing Tracker ON will turn
Tracker ON
Tracker OFF = Tracker is currently turned on and pressing Tracker OFF will turn
Tracker OFF
– Single-channel pipettes:
Select the microplate (96 or 384 wellplate) and if the pipetting is done in
rows or columns, press the operating button or OK to activate the Tracker.
First dispensing is shown on display:
Rows: A1 - A2 - A3… B1 - B2 - B3… C1 - C2 - C3…
Columns: 1A - 1B - 1C… 2A - 2B - 2C… 3A - 3B - 3C…
The first dispensing location can be selected as desired.
– 8-channel pipettes:
Select the microplate (96 or 384 wellplate). Pipetting is possible in columns.
Press operating button or OK to activate the Tracker.
96-well plate (Columns): 1, 2, 3…
384-well plate (Columns):
1. Pipetting: A1 – C1 – G1…
2. Pipetting: B1 – D1 – F1…
3. Pipetting: A2 – C2 – G2…
4. Pipetting: B2 – D2 – F2…
The first dispensing column can be selected as desired.
– 12-channel pipettes:
Select the microplate (96 or 384 well plate). Pipetting is possible in rows.
Press operating button or OK to activate the Tracker.
96-well plate (Rows): A, B, C…
384-well plate (Rows):
1. Pipetting: A1 – A3 - A5…
2. Pipetting: A2 – A4 – A6…
3. Pipetting: B1 – B3 - B5...
4. Pipetting: B2 – B4 – B6…
The first dispensing row can be selected as desired.
2. Counter (Pipetting, Rev. Pipetting)
Cycle counter counts the pipetting cycles up to 99. It is possible to start
counting from any desired number up to 99.
Counter ON = Counter is currently OFF and pressing Counter ON will turn
Counter ON
Counter OFF = Counter is currently turned on and pressing Counter OFF will
turn Counter OFF
