Description of the Equipment
The Combics scales from Sartorius are primarily used in industry. Because there are a number of hardware configurations
to choose from, Combics models are constructed according to customer requirements.
The Combics scale consists of:
– A choice of weighing platforms with capacities from 10 lbs to 10000 lbs (in stainless steel or steel) and indicators
The Combics 1 / 2 indicators consist of:
– Front panel with keypad and
digital display (Combics 2 has
additional keys and LEDs)
– Combics indicators
are equipped with either cable
glands or D-Sub 25
connectors.
Note: Additional electronic subassemblies are optional.
Digital PCB with application
processor, memory, RS-232 interfaces
Analog/digital converter
Power PCB
DC/DC converter
(Combics2 has a clock chip)
combics_15_klemmen.eps
Combics 2
