51
Important: Calibration without weights cannot be
performed on weighing instruments used in
legal metrology.
Storing Configuration Data (Menu Item 11-10)
Select menu item 11-10-1 to store the A/D converter
configuration data.
Once these parameters have been configured, the A/D
converter in conjunction with the load cell is defined as a
weighing instrument. The A/D converter, in conjunction
with the weighing platform, can now be used like any
standard weighing platform.
In addition, the weight unit must be defined and the
weighing platform adjusted (calibration/adjustment
and linearization must be performed). For a detailed
description of these procedures, see the chapter entitled
“Calibration/Adjustment in Service Mode”.
Important: After configuring the A/D converter
and adjusting the weighing instrument
(calibration/adjustment and linearization),
return the menu access switch to the
“closed” position (i.e. for use in legal
metrology). Turn the Combics indicator off
and then on again (key sequence: e e
to activate the new configuration.
Once the A/D converter configuration has been locked
(menu access switch closed), the indicator can no longer
be used to influence weighing results. The scope of
functions available in the weighing instrument is defined
by the A/D converter. Scale functions which can be
activated are, for example: weight readout, taring,
adjustment, reading tare value, saving/deleting tare values.
