Operating Instructions Combics Indicators 109
Example: Output weight value of +1255.7 g
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
G # * * * * + * * * 1 2 5 5 . 7 * g * * CR LF
Positions 1-6: ID code, right-justifi ed with spaces
Position 7: Plus +, or minus - or space
Position 8: Space
Positions 9-16: Weight value with decimal point; leading zeros are output as
spaces (a comma can also be set instead of a decimal point,
menu item 7.17).
Position 17: Space
Positions 18-20: Characters for unit of measure, space or ! sign as a symbol
Position 21: Carriage return
Position 22: Line feed
h
If the weight value is output with 10-fold increased resolution, this value is not
permitted to be printed or saved in a weighing instrument operated in legal
metrology in the SBI mode. In this case, the unit symbol is not included with output.
Error message
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
S t a t * * * * * E r r * * # # * * * * CR LF
S t a t * * * * * E r r * # # # * * * * CR LF
*: Space
#: Number (2 or 3 digit error number)
G# Gross value
N Net value
T Application tare memory 1
T2 Application tare memory 2
Diff Difference from calibration
value
Targ. Exact adjustment weight
value
Nom. Exact calibration weight
for SBI protocol output
nRef Reference sample quantity
pRef Percentage of reference
wRef Reference piece weight
Qnt Result from Counting (piece
count) and Neutral
Measurement applications
mDef Target value for animal
weighing
x-Net Animal weighing results
Setp Target value for
checkweighing
Diff.W Absolute difference (e.g., in
kg) in Checkweighing
Lim Deviation in % in
Checkweighing
Max Upper tolerance for checkw.
Min Min. tolerance for checkw.
Stat Status
Classx Classifi cation
Limx Class limit
D Percentage (as loss)
Prc Percentage (as residue)
Wxx% Reference percentage weight
Cmpxxx Component xxx
Cont.T Contents of the tare memory
in Net-total Formulation
S-Comp Total of initial weighings for
Net-total formulation
PT2 Preset tare
n Transaction counter
*G Sum of gross weights in
Totalizing
*N Sum of net weights in
Totalizing
Ser.no Serial number of the platform
or indicator
Data Interfaces
