Setup information – External linearization when weighing in legal metrology is only possible when
the menu access switch is open.
– The “external linearization" function must be allocated to the J key (menu
item 1.9.6 or 1.9.7).
3
Once linearization has been completed, the J key must be reallocated back to its
original function in the Setup menu, e.g. external calibration/adjustment with
default weights (Setup menu item 1.9).
Procedure
t For scales used in legal metrology: open the menu access switch.
( t Zero the weighing platform.
t Activate the Service mode (see Page 17).
J t Start linearization.
t After approximately 2 seconds you will be prompted to place the first
linearization weight on the platform.
t Place the required weight on the platform.
y After a short time the difference between the measured value and the true
weight of the sample will be displayed.
) t Save the linearization weight (cancel using the ( key).
y You will then be prompted to place the second linearization weight on the
platform.
t Repeat the procedure for all required linearization weights.
y After the last linearization weight has been saved you will be prompted to
remove any load from the weighing pan.
t Unload the weighing pan.
t After a short period of time the zero point will be applied automatically and the
indicator will automatically switch back to weighing mode.
t Re-close the menu access switch.
Operating Instructions Combics Indicators 27
Configuring Weighing Platforms
