Entering Adjustment and Linearization Weights
Purpose Entering adjustment and linearization weights.
Setup information – The Service mode must be activated in order for linearization weights to be
entered under menu items 1.18.2 to 1.18.5 (see page 17).
– Adjustment and linearization weights can be entered in the Setup menu under
“WP-1” for the first weighing platform and COm1 / WP-2, UNICOM / WP-2 or
COm-WP for the second weighing platform. The settings are made in the
corresponding Setup menu under menu item 1.18.
– The Service mode does not have to be activated in order for external user-
defined adjustment weights to be entered under menu item 1.18.1.
– The adjustment and linearization weights must be entered in the unit selected
for the ADC configuration under menu item 11.8.
Procedure t Activate the Service mode (only necessary if linearization weights are going to
be entered)
t Select the weighing platform.
t Enter the external user-defined adjustment weight under menu item 1.18.1
t Enter the external linearization weight under menu items 1.18.2 to 1.18.5.
Menu structure for entering the adjustment and linearization weights
HND.XTEntering the adjustment and linearization weights 1.18.
Entering external user-defined adjustment weight (Service mode not required) 1.18.1
LIN. WT.1 Entering the lin. weight 1 1.18.2
LIN. WT.2 Entering the lin. weight 2 1.18.3
LIN. WT.3 Entering the lin. weight 3 1.18.4
LIN. WT.4 Entering the lin. weight 4 1.18.5
Function Allocation of the J Key
Purpose The J key is usually used for the calibration/adjustment function. For detailed
information about calibration and adjustment, see “Operation” starting on page 47.
The following additional functions can be allocated to the key when the Service
mode is activated:
– External linearization with default weights (menu item 1.9.6)
– External linearization with the linearization weights (menu item 1.9.7) entered
under menu item 1.18
– Internal linearization (for WP-2 only) (menu item 1.9.5)
– Set preload function (menu item 1.9.8) (possible without legal metrology)
– Clear preload function (menu item 1.9.9) (possible without legal metrology)
3
Once linearization has been completed, or after a preload has been set or cleared
the function of the J key must be reallocated back to its original function in the
Setup menu, e.g. external calibration/adjustment with default weights (Setup menu
item 1.9).
Menu structure for the function allocation of the J key
CAL./ADJ. Calibration, adjustment 1.9.
Ext. calibration/adjustment with default weights (Service mode not required) 1.9.1
Ext. calibration/adjustment with user-defined weights
(Entry under 1.18, Service mode not required) 1.9.3
CAL.INT Internal linearization (for WP-2 only) 1.9.5
CAL.EXT External linearization with default weights 1.9.6
CAL.E.USR. External linearization with user-defined weights (entered under 1.18) 1.9.7
SET.PREL. Setting the preload 1.9.8
DEL.PREL. Clearing the preload 1.9.9
BLOCKED Key blocked 1.9.10
External Linearization
26 Operating Instructions Combics Indicators
Configuring Weighing Platforms
