Operating Instructions Combics Indicators 113
"Checkweighing" application:
The initialization data contains the
target weight, the min. weight and
the max. weight. The results data
always contains the gross, net and
tare weight. Additional results can
be printed in 2 different display
types:
– Weight display:
In the OK and nonconforming
range, the deviation from the target
weight is always printed as a
percentage and absolute deviation.
– Relation to target value:
In the OK range, the deviation from
the target weight is printed as a
percentage and absolute deviation.
In the nonconforming range, “HH"
is printed for exceeding the weight
and “LL" for falling below the
weight.
OK range in the weight and
tolerance limit display
--------------------
Setp + 1.300 kg
Min + 1.235 kg
Max + 1.365 kg
G# + 1.312 kg
T + 0.000 kg
N + 1.312 kg
Lim + 0.92 %
Diff.W+ 0.012 kg
--------------------
Result outside (over) “OK” range;
“Threshold” printout:
--------------------
Setp + 1.300 kg
Min + 1.235 kg
Max + 1.365 kg
G# + 1.400 kg
T + 0.000 kg
N + 1.400 kg
Stat HH
--------------------
Sample Printouts
For details on the individual
information blocks, see “Configuring
Printouts”, above. For details on
configuring the header lines, refer to
the chapter of the respective
application.
"Weighing" application:
If selected, an empty line will be
printed.
HEADER LINE1
HEADER LINE2
14.01.2012 09:43
--------------------
G# + 1.402 kg
T + 0.200 kg
N + 1.202 kg
--------------------
Display with ID of weighing platfor
--------------------
Ser.no. 80705337
G# + 1.402 kg
T + 0.200 kg
N + 1.202 kg
--------------------
"Counting" application:
The initialization data contains the
reference sample quantity and the
reference sample weight. The results
data contains gross, net and tare
weight and the piece count as a
result.
--------------------
nRef 10 pcs
wRef + 0.035 kg
G# + 1.402 kg
T + 0.212 kg
N + 1.190 kg
Qnt 34 pcs
--------------------
"Neutral Measurement"
application:
The initialization data block
contains the reference sample
quantity and reference weight. The
results block contains gross, net and
tare weight and the piece count as a
result.
--------------------
Ref 2 o
wRef + 1.200 kg
G# + 14.700 kg
T + 0.300 kg
N + 14.400 kg
Qnt 12 o
--------------------
"Weighing in Percent" application:
The initialization data contains the
reference percentage and the
reference sample weight. The results
data shows gross, net and tare
weights, as well as the percentage,
which is shown as either the loss or
the residual amount.
Percentage = residue:
--------------------
pRef 100 %
Wxx% + 2.100 kg
G# + 1.859 kg
T + 0.200 kg
N + 1.659 kg
Prc 79 %
--------------------
Percentage = loss:
--------------------
pRef 100 %
Wxx% + 2.100 kg
G# + 0.641 kg
T + 0.200 kg
N + 0.441 kg
D 21 %
--------------------
Data Interfaces
