Example: 25 m of electrical cable is to be measured.
Configuration: The “Neutral Measurement" application is selected, and printout
has been set up (see “Configuration").
t Place empty container on the scale.
) t Tare the scale.
This is not required if the automatic tare function is active. The tare weight
is saved automatically when you place the container on the platform.
2 4 8 t Enter the weight of 1 meter of cable using the keypad (in this example, 248
g).
O t Save the value entered.
or
r t Set the number of reference parts using r: 1, 2, 5, 10, 20, etc.
O t Start the calculation of the reference piece weight.
t Place the desired amount of cable into the container (25 m in this
example).
y The result is displayed.
p t Print results (Configuring Printouts: see page 96)
nRef + 1 o
wRef + 0.248 kg
G# + 6.794 kg
T + 0.541 kg
N + 6.253 kg
Qnt 25 o
--------------------
Averaging (Animal Weighing) V (Combics 2)
62 Operating Instructions Combics Indicators
Operation
