Sartorius MIS2 - Selecting the Adjustment Resistor; Adjusting Off-Center Load with 1000 Ohms Initial Resistance

42
Adjusting the Weighing Platform
Adjustment
resistor
(in ohm)
Test weight
50kg
Test weight
100kg
Test weight
200kg
Test weight
500kg
Test weight
1000kg
0
0.00 - 0.02 0.00 - 0.05 0.0 - 0.1 0.0 - 0.1 0.0 - 0.3
0.39
0.02 - 0.04 0.05 - 0.07 0.1 - 0.1 0.1 - 0.4 0.3 - 0.7
0.82
0.04 - 0.06 0.08 - 0.11 0.1 - 0.2 0.4 - 0.5 0.8 - 1.1
1.2
0.06 - 0.07 0.12 - 0.15 0.2 - 0.3 0.6 - 0.8 1.2 - 1.5
1.6
0.08 - 0.09 0.16 - 0.19 0.3 - 0.4 0.8 - 1.0 1.6 - 1.9
2
0.1 - 0.13 0.20 - 0.26 0.4 - 0.5 1.0 - 1.3 2.0 - 2.6
2.7
0.13 - 0.14 0.27 - 0.29 0.5 - 0.6 1.3 - 1.5 2.7 - 2.9
3
0.15 - 0.16 0.30 - 0.32 0.6 - 0.7 1.5 - 1.6 3.0 - 3.2
3.3
0.16 - 0.19 0.33 - 0.38 0.7 - 0.8 1.6 - 1.9 3.3 - 3.8
3.9
0.19 - 0.23 0.39 - 0.46 0.8 - 0.9 1.9 - 2.3 3.9 - 4.6
4.7
0.23 - 0.27 0.47 - 0.55 0.9 - 1.1 2.3 - 2.7 4.7 - 5.5
5.6
0.20 - 0.33 0.56 - 0.66 1.1 - 1.3 2.8 - 3.1 5.6 - 6.6
Selecting the Adjustment Resistor
Adjusting Off-center Load with 1000 Ohms Initial Resistance
Off-center (in k
g
)
Important: These are calculated (estimated) values
