Specifications
Maximum readability 15,000 scale intervals (in not legal metrology)
Accuracy class l and m (for “..-.CE" models)
Verification scale intervals (example) < 3000e (single-range scale) or 2+ 3000e (multiple-range scale) acc. to EN 45501
Digital protective interface in accordance with EN 45501
Data interface optional
Display 14 segments; backlit
Ambient conditions:
Operating temperature range -10°C to +40°C (+14°F to 104°C)
Humidity Maximum relative humidity 80% for temperature up to 31°C (~88°F);
linear decrease down to 50% relative humidity at 40°C (+104°F)
Protection class of the housing
in accordance with EN 60529 IP 65
Pollution degree 2 Normally only nonconductive pollution occurs. Temporary conductivity caused by
condensation is to be expected.
Ratings:
Power supply 100-240 VAC (-15/+10%), 50-60 Hz, 17 W/23 VA max.
Transient overvoltage Overvoltage category II acc. to IEC 60364-4-443
Operation using protective extra low voltage See instruction manual for Option L8 (24-volt module)
DC supply 22.8 ... 26.7 V (optional: 21.6 ... 26.7 V); 12 VA max.
AC supply 22.8 ... 26.7 V, 50-60 Hz, 12 VA max.
Operation with rechargeable battery See Sartorius Installation Instructions for Option L9
Operation via built-in or external rechargeable battery (only available as an option that must
be ordered with the scale)
Emissions Acc. to EN613-1 (IEC 61326-1)
Group 1, Class B, suitable for use in domestic establishments and establishments directly
connected to a low-voltage power-supply network that supplies buildings used for domestic
purposes
Immunity to interference: Acc. to EN61326-1):
Immunity test requirements for equipment intended for use in industrial locations (Table 2)
Electrical safety Acc. to EN 61010-1 (IEC 1010-1)
Platform Specifications
Model code: MW...-L MW...-LCE MW....-NCE (2+3000e)
Type: SARTICS SARTICS
Approval no.: D04-09-015 D04-09-015
Readability Readability Weighing range 1 Weighing range 2
Weighing capacity 15000d 1+3000e Maximum capacity Readability Maximum capacity Readability
3 kg 0.2 g 1 g 1.5 kg 0.5 g 3 kg 1 g
6 kg 0.5 g 2 g 3 kg 1 g 6 kg 2 g
15 kg 1 g 5 g 6 kg 2 g 15 kg 5 g
30 kg 2 g 10 g 15 kg 5 g 30 kg 10 g
60 kg 5 g 20 g 30 kg 10 g 60 kg 20 g
150 kg 10 g 50 g 60 kg 20 g 150 kg 50 g
300 kg 20 g 100 g 150 kg 50 g 300 kg 100 g
600 kg 50 g 200 g 300 kg 100 g 600 kg 200 g
1500 kg 100 g 500 g 600 kg 200 g 1500 kg 500 g
3000 kg 200 g 1000 g 1500 kg 500 g 3000 kg 1000 g
