Chapter 1 Introduction 3
The roll value may be changed in accordance with the average
load of the power line. For example, if average power equals 400
kW and the counter must reset every 3 months (2160 hours),
then energy during this period equals 864000 (6 digits) and the
roll = 10.E6.
Phase energy calculations mode (Ph.En)
This option is used to enable or disable phase energy calculations.
Measured Parameters
Note: Real-time values are measured over 1 cycle of fundamental frequency;
Average values are of 8, 16 or 32 real-time values
available in the PM130P/PM130E
Output
Parameter Display Comm. Pulse Alarm
Average Values: Amps, Volts,
Frequency
$ = setup via PC
# = setup via panel
Average RMS Voltage per phase
#$
Average RMS Current per phase
#$
Average Frequency
#$
Average Neutral Current
#$
Voltage & Current unbalance
Amps & Volt Demand Parameters
Ampere Demand per phase
#$
Volt Demand per phase
#$
Ampere Maximum Demand per phase
Voltage Max. Demand per phase
Average Power values
Average Active Power per phase
Average Reactive Power per phase
Average Apparent Power per phase
Average Total Active Power
#$
Average Total Reactive Power
#$
Average Total Apparent Power
#$
Average Power Factor per phase
Average Total Power Factor
#$
Power Demand Parameters
Active Power Accumulated Demand
#$
Apparent Power Accumulated Demand
#$
Active Power Demand
#$
Active Power Sliding Demand
#$
Apparent Power Demand
#$
Apparent Power Sliding Demand
#$
Active Power Predicted Demand
#$
Apparent Power Predicted Demand
#$
P
P E
P E
E
P E
P E
To Next Page
