Chapter 5 Data Display
34
Fast Reset of Accumulated Data
When changing data via the front panel is not secured by a
password, you can reset the Min/Max registers, maximum
demands and energies from the display mode without entering the
reset menu.
Select the display page of the data you want to reset. To reset:
• Min/Max log registers: select a Min/Max page from the
Min/Max measurements display (where a Max or Min round
LED is illuminated).
• Ampere and volt maximum demands: select the ampere or
volt maximum demand page from the Min/Max
measurements display (where a MAX DMD LED is
illuminated, and volts or amps LEDs at the right are lit).
• Power maximum demands: select the power maximum
demand page from the Min/Max measurements display
(where a MAX DMD LED is illuminated, and kVA/MVA and
kW/MW LEDs at the right are lit).
• Total and phase energies: select the energy measurements
display.
While holding the key, press and hold for
about 5 seconds. The displayed data is reset to zero.
5.2 Data Display Formats
The display windows are labeled in the table as follows: 1 = upper
window, 2 = middle window, 3 = lower window.
Table 5-1 Displayed Parameters for the PM130
Page Window Indicato
