Chapter 5 Data Display 33
In the Display Mode, the front panel display is updated
approximately twice per second; you can adjust the display update
rate via the Display Setup Menu (see Section 4.6).
Tables 5-1 and 5-2 list all displayed parameters and their LED
indicators.
NOTES
1. The common measurements group does not have a designated
indicator LED. If no indicator LED is lit up below the display, this means
that the common measurement parameters are being displayed at this
time. To return to the common measurements from another group, just
press the same key that you used to display this group (the key pointed
to by an illuminated LED).
2. When you move to another measurement group, the instrument stores
your last location; when you return to the previous group, the
instrument restores the last page. At power up, the instrument always
returns to the common measurements group and shows you the last
page that was displayed prior to loss of power.
Selecting a Display Page
 Press the up/down arrow keys to scroll through display pages.
Selecting Common Measurements
 Press the key pointed to by the illuminated round LED below the
front panel display. If no LED is lit up, this means that the front
panel displays the common measurements parameters.
When Display Auto Scroll is in effect (see Section 4.6), the
display will scroll automatically within 30 seconds after any of
the following:
• power up
• returning to the common measurements display
• pressing either arrow key
 Press either arrow key to pause scrolling at the current page.
Selecting Min/Max Measurements
 Press the key. Use the up/down arrow keys to scroll
through Min/Max measurements.
Selecting Energy Measurements
 Press the key. Use the up/down arrow keys to scroll
through the different energy readings.
Auto Return to the Main Screen
If display Auto Return option is enabled (see Section 4.6), the
display will automatically return to the main screen from any other
measurement screen after 30 seconds of uninterrupted use.
MAX/MIN
ENERG
Y
