Chapter 2 Installation
6
Chapter 2 Installation
2.
2.1 Mechanical Installation
1- Position Powermeter in cut-out
2- Affix the Powermeter using washers and nuts
Figure
2-1 Mounting the PM130 (Square or Round Cut-out)
