Chapter 4 Setup Menus 19
Chapter 4 Setup Menus
4. CHAPTER 3 SETUP MENUS
NOTE: Instrument setup can be performed directly on the front
panel using the setup menus or via communications using
PComTest communication software. PComTest is supplied with your
instrument and provides full setup capabilities for your instrument.
For information on using PComTest, refer to the user documentation
supplied with your instrument.
4.1 Basic Setup Menu
This menu contains the basic configuration options which define
the general operating characteristics of your instrument, such as
wiring mode, input scales, the size of the RMS averaging buffer,
etc. Table 4-1 lists the basic setup options, their code names and
applicable ranges.
Activate the middle window to scroll through the list of available
options, and then activate the lower window to set the option
value.
To select and view a setup option:
Press to activate the middle window
Use the up/down arrow keys to scroll to the desired option.
The current value for this option appears in the lower
window.
To change the value of the selected option:
Press to make the lower window active.
Press the up/down arrow keys to scroll to the desired
value.
Press to store the selected value, or press
to quit the setup menu.
Table 4-1 Basic Setup Options (∗ default setting)
Code Parameter Options Description
ConF
Wiring mode 3OP2 3-wire open delta using 2 CTs
(2 element)
4Ln3∗
4-wire Wye using 3 PTs (3 element),
line to neutral voltage readings
3dir2 3-wire direct connection using 2 CTs
(2 element)
4LL3 4-wire Wye using 3 PTs (3 element),
line to line voltage readings
SELECT
SELECT
bASc
4L-n
ConF
ENTER
ESC
SELECT
CH
To Next Page
