Satec PM130P User Manual

Chapter 6 Viewing Status Information
42
 While holding the key, press and hold for
about 5 seconds until the alarm trigger code displayed in the
lower window changes to "none".
Fast Reset of Counters
When changing data via the front panel is not secured by a
password, you can reset the counters from the Status Information
Menu display without entering the reset menu:
 Select the page where the counter you want to reset is displayed.
 While holding the key, press and hold for
about 5 seconds. The displayed data is reset to zero.
6.2 Status Display Formats
Table 6-1 lists all the displays available from the Status
Information Menu. The display windows are labeled in the table as
follows: 1 = upper window, 2 = middle window, 3 = lower window.
Table 6-1 Status Information
Page Window Parameter Digits Unit
1 1
PHAS
Label
1 2
rOt
Label
1 3 Phase rotation sequence
(POS/NEG/ERR)
4
2 1
rEL
Label
2 3 Relay status 1
3 1
Cnt.1
Label
3 3 Counter #1 5
4 1
Cnt.2
Label
4 3 Counter #2 5
5 1
Cnt.3
Label
5 3 Counter #3 5
6 1
Cnt.4
Label
6 3 Counter #4 5
7 1
Port
Label
7 2
rd. Receiver status (flashing r
while receiving data)
1
7 3
td. Transmitter status (flashing t
while transmitting data)
1
8 1
Alar
Label
8 2
SP. Alarm setpoint number
4
8 3 Alarm trigger code (see Table 4-5) 5
P E
SELECT
ENTER
SELECT
ENTER
available in the PM130P
P
available in the PM130E
E
