Chapter 3 Using the Menus 17
Chapter 3 Using The Menus
3.
Press to enter the setup mode. The primary menus will
appear:
Press again to activate the window of the desired primary
menu. Press
.
Select CHG to initialize or modify the instrument setup, or to clear
the accumulated values stored in the instrument. Entry to this
menu can be protected by a password.
Select StA to view extended status information which may be
useful during installation and in certain applications.
Select OPS for viewing (not editing) the instrument setup options.
After selecting either OPS or CHG, the list of setup menus is
displayed in the upper window. Figure 3-1 presents a complete
menu list. Depending on the model of your instrument, some
menus may not appear.
Password
The Setup Change Menu can be secured by a user-defined
password comprised of 4 digits. The instrument is shipped with
password protection disabled. To enable password protection, go
to the Access Control Menu (see Section 4.13).
The Password Menu appears if password protection is enabled.
To enter a password:
Set the first digit using the up and down arrow keys.
Press to advance to the next digit. As you
advance, the previous digit will become invisible.
Set the other password digits in the same manner.
Press to continue setup. If your password is incorrect,
you will return to the Primary Selection Menu.
SELECT
SELECT
ENTER
SELECT
StA
ENTER
To Next Page
