4.6 Display Setup Menu
This menu allows you to view and change display properties.
Table 4-7 lists available options with their code names and
applicable ranges.
Table 4-7 Display Options (∗ default setting)
Display Code Parameter Options Description
UPdt
Update
time
0.1 – 10.0 s
(0.5)*
defines interval
between display
updates
ScrL
Auto scroll
interval
nonE*
2-15 s
disables/enables auto
scroll on common
measurements
display; defines auto scroll interval
rEtn
Auto return
to the main
screen
diS*, En
Disables/enables
auto return to the
main screen after 30
seconds of
uninterrupted use
bAr
Nominal
load
current for
LED bar
graph
0-50000A
(0*)
defines the nominal
load (100%) level for
the bar graph display
(0 = CT primary
current)
Ph.P
Phase
powers
display
mode
diS*, En
disables/enables
display of phase
powers in common
measurements
To select a display option:
Press to activate the middle window, and then use the
up/down arrow keys to scroll to the desired option.
To change the display option:
Press to activate the lower window.
Use the up/down arrow keys to set the desired option.
Press to store your new setting or press to leave
your previous setting unchanged.
To quit the display setup menu:
From the middle window, press or .
