Satec PM130P User Manual

Chapter 5 Data Display 35
Page Window Indicato
r
LED
Parameter

Digit
s
Unit 
Min/Max Measurements
MIN
1 1
V1/V1-2
Min. real-time voltage
L1/L12 
4 V/kV
1 2
V2/V2-3
Min. real-time voltage
L2/L23 
4 V/kV
1 3
V3/V3-1
Min. real-time voltage
L3/L31 
4 V/kV
MAX
2 1
V1/V1-2
Max. real-time voltage L1/L12  4 V/kV
2 2
V2/V2-3
Max. real-time voltage L2/L23  4 V/kV
2 3
V3/V3-1
Max. real-time voltage L3/L31  4 V/kV
MAX DMD
3 1
A1
Max. ampere demand L1 4 A/kA
3 2
A2
Max. ampere demand L2 4 A/kA
3 3
A3
Max. ampere demand L3 4 A/kA
 Displayed readings for all electrical quantities except Min/Max log are sliding
average values.
 Voltage and current readings with a decimal point are displayed in kV and
kA. When the value width exceeds the window resolution, the right-most
digits are truncated.
 When the 4LN3 or 3LN3 wiring mode is selected, the voltages will be line-to-
neutral; for any other wiring mode, they will be line-to-line voltages.
 Displayed only in the 4LN3 or 3LN3 wiring mode.
 ' L' and ' P' indicators appear only in the case of 4LN3 or 3LN3 wiring
modes where both line-to-line and line-to-neutral voltages are present.
