Satec PM130P User Manual

Chapter 5 Data Display
36
Table 5-2 Displayed Parameters for the PM130P/PM130E
Page Window Indicator
LED
Parameter
 Digits Unit 
Common Measurements
1 1
V1/V1-2
Voltage L12 4 V/kV
1 2
V2/V2-3
Voltage L23 4 V/kV
1 3
V3/V3-1 L. Voltage L31
4 V/kV
2 1
V1/V1-2
Voltage L1  4 V/kV
2 2
V2/V2-3
Voltage L2  4 V/kV
2 3
V3/V3-1 P. Voltage L3 
4 V/kV
3 1
A1
Current L1 4 A/kA
3 2
A2
Current L2 4 A/kA
3 3
A3
Current L3 4 A/kA
4 1
kVA
Total kVA 4 kVA/MVA
4 2
PF
Total power factor 4
4 3
kW
Total kW 4 kW/MW
5 1
A NEUT
Neutral current 4 A/kA
5 2
Hz
Frequency 4 Hz
5 3
kvar
Total kvar 4 kvar/Mvar
6 1
Ph.L1 
Label
6 2
PF
Power factor L1 4
6 3
kW
kW L1 4 kW/MW
7 1
kVA
kVA L1 4 kVA/MVA
7 2
Ph.L1 
Label
7 3
kvar
kvar L1 4 kvar/Mvar
8 1
Ph.L2 
Label
8 2
PF
Power factor L2 4
8 3
kW
kW L2 4 kW/MW
9 1
kVA
kVA L2 4 kVA/MVA
9 2
Ph.L2 
Label
9 3
kvar
kvar L2 4 kvar/Mvar
10 1
Ph.L3 
Label
10 2
PF
Power factor L3 4
10 3
kW
kW L3 4 kW/MW
11 1
kVA
kVA L3 4 kVA/MVA
11 2
Ph.L3 
Label
11 3
kvar
kvar L3 4 kvar/Mvar
12 1
U.Unb
Label
12 3 Voltage unbalance 4 %
13 1
C.Unb
Label
13 3 Current unbalance 4 %
