Satec PM130P User Manual

Chapter 5 Data Display 37
Page Window Indicator
LED
Parameter
 Digits Unit 
Min/Max Measurements
MIN
1 1
V1/V1-2
Min. real-time voltage
L1/L12 
4 V/kV
1 2
V2/V2-3
Min. real-time voltage
L2/L23 
4 V/kV
1 3
V3/V3-1
Min. real-time voltage
L3/L31 
4 V/kV
2 1
A1
Min. real-time current L1 4 A/kA
2 2
A2
Min. real-time current L2 4 A/kA
2 3
A3
Min. real-time current L3 4 A/kA
3 1
kVA
Min. real-time total kVA 4 kVA/MVA
3 2
PF
Min. real-time total power
factor
4
3 3
kW
Min. real-time total kW 4 kW/MW
4 1
A NEUT
Min. real-time neutral
current
4 A/kA
4 2
Hz
Min. real-time frequency 4 Hz
4 3
kvar
Min. real-time total kvar 4 kvar/Mvar
MAX
5 1
V1/V1-2
Max. real-time voltage
L1/L12 
4 V/kV
5 2
V2/V2-3
Max. real-time voltage
L2/L23 
4 V/kV
5 3
V3/V3-1
Max. real-time voltage
L3/L31 
4 V/kV
6 1
A1
Max. real-time current L1 4 A/kA
6 2
A2
Max. real-time current L2 4 A/kA
6 3
A3
Max. real-time current L3 4 A/kA
7 1
kVA
Max. real-time total kVA 4 kVA/MVA
7 2
PF
Max. real-time total power
factor
4
7 3
kW
Max. real-time total kW 4 kW/MW
8 1
A NEUT
Max. real-time neutral
current
4 A/kA
8 2
Hz
Max. real-time frequency 4 Hz
8 3
kvar
Max. real-time total kvar 4 kvar/Mvar
MAX DMD
9 1
V1
Max. volt demand L1/L12 4 V/kV
9 2
V2
Max. volt demand L2/L23 4 V/kV
9 3
V3
Max. volt demand L3/L31 4 V/kV
