Satec PM130P User Manual

Chapter 5 Data Display
38
Page Window Indicator
LED
Parameter
 Digits Unit 
10 1
A1
Max. ampere demand L1 4 A/kA
10 2
A2
Max. ampere demand L2 4 A/kA
10 3
A3
Max. ampere demand L3 4 A/kA
11 1
kVA
Max. sliding window kVA
demand
4 kVA/MVA
11 2
PF
Power factor at max. kVA
demand
4
11 3
kW
Max. sliding window kW
demand
4 kW/MW
Total Energies 
1 1
MWh Ac.En.
Label
1 2
IP.
Label
1 3 MWh import 5 MWh
2 1
Mvarh rE.En.
Label
2 2
IP.
Label
2 3 Mvarh import 5 Mvarh
3 1
MVAh AP.En.
Label
3 3 MVAh 5 MVAh
4 1
MWh Ac.En.
Label
4 2
EP.
Label
4 3 MWh export 5 MWh
5 1
Mvarh rE.En.
Label
5 2
EP.
Label
5 3 Mvarh export 5 Mvarh
Phase Energies 
6 1
MWh Ac.En.
Label
6 2
IP.L1
Label
6 3 MWh import L1 5 MWh
7 1
Mvarh rE.En.
Label
7 2
IP.L1
Label
7 3 Mvarh import L1 5 Mvarh
8 1
MVAh AP.En.
Label
8 2
L1
Label
8 3 MVAh L1 5 MVAh
9 1
MWh Ac.En.
Label
9 2
IP.L2
Label
9 3 MWh import L2 5 MWh
10 1
Mvarh rE.En.
Label
10 2
IP.L2
Label
10 3 Mvarh import L2 5 Mvarh
E
E
E
E
